CARLO GAVAZZI RGC1P48K62ED Solid State Relay
The RGC1P48K62ED is a solid state relay featuring soft start switching designed for high inrush loads like infrared heaters. It offers three-phase control with integrated overload protection via varistor, rated operational voltage of 410-660 VAC, and control input of 24 VDC. Suitable for industrial applications, it enables smooth load start-up, reduces electrical stress, and has LED indicators for status. Its compact DIN or panel mounting, high short circuit current rating, and compliance with UL and IEC standards make it reliable for demanding environments. Encompassing technical features such as surge protection, IP20 touch protection, and an operational temperature range of -40°C to +70°C, the relay ensures safety and durability in automation and control systems.
CARLO GAVAZZI RGC1P48K62ED Solid State Relay Specifications:
- Operational voltage range: 410 - 660 VAC
- Blocking voltage: 1200 Vp
- Leakage current: <5 mAAC at rated voltage
- Rated operational current: 73 AAC (at 40°C for model 62)
- Minimum operational current: 500 mAAC
- Maximum transient surge current: 1900 Ap
- Short circuit current rating: 100kArms
- Control input: 24 VDC, pick up at 19.2 VDC, drop out at 10 VDC, response time: 2 half cycles
- Supply voltage range: > 24 VDC, -15% / +20%; Overvoltage protection: up to 32 VDC/AC
- Operating temperature: -40°C to +70°C; Storage: -40°C to +100°C
- Protection class: IP20, UL flammability rating: UL 94 VO
- Dimensions: approx. 805g weight, width varies with model, installation on DIN rail or panel
- Environmental: Humidity up to 95% non-condensing, vibration resistance, impact resistance
- Standards: UL508, IEC/EN 60947-4-3, RoHS compliant
Buy the Carlo Gavazzi RGC1P48K62ED – Reliable Solid State Relay for Industrial Applications
Upgrade your industrial control systems with the Carlo Gavazzi RGC1P48K62ED solid state relay. Featuring soft start switching, integrated overload protection, and a wide operating voltage range of 410 to 660 VAC, this relay ensures smooth load startup and reliable performance. It is designed for high inrush loads like infrared heaters and offers a compact, DIN or panel mounting option. With UL and IEC compliance, IP20 protection, and excellent transient surge handling, this relay boosts automation efficiency and safety. Purchase online now for premium control reliability.
Order your Carlo Gavazzi RGC1P48K62ED solid state relay today and enhance your load control with dependable soft start switching in demanding environments.
Frequently Asked Questions
Where can I buy CARLO GAVAZZI RGC1P48K62ED?
You can click on the BUY or RFQ button to purchase RGC1P48K62ED from an authorized CARLO GAVAZZI distributor.
How do I troubleshoot issues or seek technical support for part RGC1P48K62ED?
You can download the RGC1P48K62ED datasheet or visit the CARLO GAVAZZI website for support.
Who is the manufacturer of RGC1P48K62ED?
CARLO GAVAZZI
