CARLO GAVAZZI RP1A23D5 Solid State Relay
The RP1A23D5 is a 1-pole zero cross-switching solid state relay designed for PCB mounting, providing an ideal interface between logic controls and AC loads. It supports resistive and inductive loads up to 480VAC RMS. The relay features two regulated control voltage ranges suitable for most standard input requirements, allowing easy replacement of existing PCB-mounted relays. Its advanced design includes stress-free flexible encapsulation and automated component assembly, enhancing durability. The relay offers opto-isolation and load switching through individual components, ensuring higher reliability compared to monolithic designs. Additionally, it is engineered with high surge current capacity to reduce fusing needs. The solid state technology enables it to withstand peak voltages of up to 1000V, making it suitable for controlling AC devices such as valve solenoids and small induction motors. Its gray PBT housing, tin-plated copper alloy terminals, and surface-mount technology ensure robust construction. The relay supports non-repetitive voltages of 650V, surge currents up to 250A, and is applicable in HVAC systems, motor drive and control, and lighting applications.
CARLO GAVAZZI RP1A23D5 Solid State Relay Specifications:
- Material: PBT, RAL7035
- Encapsulation: Flexible stress-free design
- Control Voltage: 3 to 32 VDC / 16 to 32 VAC
- Load Voltage: Up to 480 VACrms
- Peak Voltage: 1000 V
- Surge Current: Up to 250 A
- Isolation: Input to output 4 kVACrms
- Operating Temperature: -20°C to +70°C
- Storage Temperature: -40°C to +100°C
- Dimensions: Compact surface-mount package, designed for PCB mounting
- Weight: Approx. 20 g
Buy the Buy Carlo Gavazzi RP1A23D5 Solid State Relay Part Number RP1A23D5 Online
Purchase the Carlo Gavazzi RP1A23D5 PCB mount solid state relay online today and enjoy dependable control for AC loads up to 480VAC. Designed with stress-free flexible encapsulation and automated assembly, it features high surge current capacity up to 250A, a peak voltage withstand of 1000V, and excellent electrical isolation. Ideal for controlling valves, small motors, or lighting, this relay offers quick response times, high reliability, and easy replacement for existing PCB relays. Shop now to upgrade your automation and control solutions efficiently.
Order your Carlo Gavazzi RP1A23D5 series zero cross PCB relay today and ensure reliable control for AC loads up to 480VAC with high surge capacity and durability.
Frequently Asked Questions
Where can I buy CARLO GAVAZZI RP1A23D5?
You can click on the BUY or RFQ button to purchase RP1A23D5 from an authorized CARLO GAVAZZI distributor.
How do I troubleshoot issues or seek technical support for part RP1A23D5?
You can download the RP1A23D5 datasheet or visit the CARLO GAVAZZI website for support.
Who is the manufacturer of RP1A23D5?
CARLO GAVAZZI
