CARLO GAVAZZI RP1B23D10 Solid State Relay
The RP1B23D10 is a compact PCB-mounted solid state relay designed for switching resistive and inductive loads up to 480 VACrms. It features zero-cross switching and instant-on modes, supporting up to 25 AACrms with forced air cooling. Its high isolation voltage of > 4000 VACrms and a blocking voltage of up to 1000 Vp make it suitable for controlling heaters, motors, and lighting in industrial automation. The relay offers reliable operation with control voltage of 4 to 32 VDC, integrated heatsink, and robust insulating features for safety and durability.
CARLO GAVAZZI RP1B23D10 Solid State Relay Specifications:
- Control Voltage: 4 to 32 VDC
- Rated Operational Current: 10 AACrms, 25 AACrms with forced air cooling
- Rated Operational Voltage: Up to 480 VACrms
- Blocking Voltage: Up to 1000 Vp
- Opto-isolation: > 4000 VACrms
- Surge Current: Up to 250 Ap
- Surface Mount Technology (SMT)
- Material: Black Epoxy coating
- Weight: Approx. 40 g
- Isolation: Input to output 4 kVACrms
- Dimensions: 37mm x 43mm
- Encapsulation: Compact design with integral heatsink
- Load Switching: Resistive and inductive loads, high reliability
- Application: Switch heaters, motors, lights, valves, solenoids
- Operating Temperature: -30°C to +80°C
- Pollution Degree: 2
- Certifications: EN 60947-4-3, UL508
Buy the Carlo Gavazzi Series RC Series Switching Device: RP1B23D10
Purchase the Carlo Gavazzi RP1B23D10 solid state relay online today for efficient control of AC loads up to 480 VAC. Designed for resistive and inductive loads, it offers high insulation, zero-cross switching, and robust performance. Ideal for automation equipment, heaters, motors, and lighting systems, this reliable relay ensures safety with exceptional ratings and easy PCB mounting. Quick online buying guarantees prompt delivery and seamless integration into your automation systems, enhancing operational efficiency and safety in industrial environments.
Buy Carlo Gavazzi RP1B23D10 now and experience unmatched reliability and high-current switching capability in industrial automation applications.
Frequently Asked Questions
Where can I buy CARLO GAVAZZI RP1B23D10?
You can click on the BUY or RFQ button to purchase RP1B23D10 from an authorized CARLO GAVAZZI distributor.
How do I troubleshoot issues or seek technical support for part RP1B23D10?
You can download the RP1B23D10 datasheet or visit the CARLO GAVAZZI website for support.
Who is the manufacturer of RP1B23D10?
CARLO GAVAZZI
