CARLO GAVAZZI RP1B23D5M1 Solid State Relay
The RP1 series includes high-performance solid state relays designed for PCB mounting, offering zero-cross or instant-on AC switching up to 480 VACrms. These relays feature an encapsulation that ensures extended life and reliable operation in demanding environments. Suitable for controlling heaters, motors, lights, and solenoids, they provide control voltages between 3 to 32 VDC or 16 to 32 VAC with a high dielectric strength of > 4000 VACrms. Key attributes include a blocking voltage of up to 1000 Vp, non-repetitive surge current of 250 A, and operating currents up to 5.5 A. They conform to UL, VDE, and EN standards, with options for surface or DIN mounting, making them versatile for industrial automation applications.
CARLO GAVAZZI RP1B23D5M1 Solid State Relay Specifications:
- Control Voltage: 3 to 32 VDC / 16 to 32 VAC
- Rated Operational Voltage: Up to 480 VACrms
- Rated Operational Current: 3, 5, or 5.5 AACrms
- Blocking Voltage: Up to 1000 Vp
- Surge Current: Non-repetitive up to 250 Ap
- Switching Mode: Zero-cross or instant-on
- Surface Mount Technology with flexible encapsulation
- Opto-isolation: > 4000 VACrms
- Weight: Approx. 20 g
- Material: PBT, RAL7035, flame-retardant silicone rubber potting
- Operating Temperature: -20°C to +70°C
- Storage Temperature: -40°C to +100°C
- Pollution Degree: 2
- Compliance: UL508, EN 60947-4-3, VDE 0600-100
- Insulation Capacitance: 8 pF
- Dimensions: Customizable per model, typically compact for PCB mounting
- Standards and EMC immunity conformances detailed in datasheet
Buy the Gavazzi Series RP Series Solid State Relay: RP1B23D5M1
Order the Carlo Gavazzi RP1B23D5M1 solid state relay online today to ensure reliable switching for industrial loads. Featuring zero-cross or instant-on modes, this relay handles up to 480 VAC and 5.5 A current, making it perfect for controlling motors, heaters, and solenoids efficiently. Designed with robust encapsulation and high dielectric strength, it guarantees extended operational life even in demanding environments. Benefit from seamless online purchase and quick delivery to keep your automation system running smoothly with Gavazzi's trusted quality.
Buy Carlo Gavazzi RP1B23D5M1 now and experience unmatched reliability and performance with high current AC switching up to 480V and versatile PCB mounting options.
Frequently Asked Questions
Where can I buy CARLO GAVAZZI RP1B23D5M1?
You can click on the BUY or RFQ button to purchase RP1B23D5M1 from an authorized CARLO GAVAZZI distributor.
How do I troubleshoot issues or seek technical support for part RP1B23D5M1?
You can download the RP1B23D5M1 datasheet or visit the CARLO GAVAZZI website for support.
Who is the manufacturer of RP1B23D5M1?
CARLO GAVAZZI
