CARLO GAVAZZI RZ3A60D55 Industrial Solid State Relay
The RZ3A60D55 is a 3-pole zero switching solid-state relay designed for industrial applications. It features DC control voltage and is part of the RZ3A series. The relay can switch loads such as heating elements, motors, and transformers, with a maximum voltage capacity of up to 600VAC. It includes a built-in varistor for transient protection, ensuring durability in heavy industrial environments. For enhanced reliability and load cycle life, it incorporates three semiconductor power units soldered onto a direct copper bonded (DCB) substrate. Additional features include LED indicators for control input and over-temperature alarm status, an integral snubber network, and IP10 back-of-hand protection. Suitable for use in industrial automation, power management, and process control settings.
CARLO GAVAZZI RZ3A60D55 Industrial Solid State Relay Specifications:
- Material: Noryl
- Potting compound: Polyurethane
- Weight: Approx. 380 g
- Rated isolation voltage: Input to output: 4000 VACrms, Output to case: 4000 VACrms
- Pollution degree: 3
- Base plate: aluminum, nickel-plated for 55A; copper, nickel-plated for 75A
- Dimensions: Not specified in the data provided
- Operational voltage range: 42-660 VAC depending on model
- Operational frequency range: 45 to 65 Hz
- Blocking voltage: Up to 4600 Vp
- Rated operational current: 25A, 55A, or 75A depending on model
- Off-state leakage current: <3 mArms
- Input control voltage: 4-32 VDC or 24-275 VAC/24-50 VDC
- Pick-up voltage: 3.8 VDC or 18/20 VAC
- Drop-out voltage: 1.2 VDC or 9 VAC/DC
- Junction temperature: +125°C
- Over-temperature alarm indicator: Red LED, optional, with reset by switching control input
- Thermal resistance for heatsinks: Model dependent, ranges from approximately 0.1 to 0.7 °C/W depending on load current
- Protection certification: CE, RoHS, China RoHS
Buy the Gavazzi RZ3A60D55 – Reliable High-Voltage Industrial Solid State Relay for Heavy Loads
Purchase the Gavazzi RZ3A60D55 online today and ensure your industrial systems run smoothly. Designed to handle high voltages up to 600VAC, this relay offers zero switching technology with built-in transient protection, LED indicators for status, and optional over-temperature alarm. Its robust construction includes soldered semiconductor units on a durable DCB substrate, providing high reliability and long cycle life. Perfect for applications like motors, transformers, and heating elements, it guarantees safety and performance in demanding industrial environments.
Get Gavazzi RZ3A60D55 today—built for industrial automation, supporting up to 600VAC with transient protection and LED status indicators for long-lasting reliability.
Frequently Asked Questions
Where can I buy CARLO GAVAZZI RZ3A60D55?
You can click on the BUY or RFQ button to purchase RZ3A60D55 from an authorized CARLO GAVAZZI distributor.
How do I troubleshoot issues or seek technical support for part RZ3A60D55?
You can download the RZ3A60D55 datasheet or visit the CARLO GAVAZZI website for support.
Who is the manufacturer of RZ3A60D55?
CARLO GAVAZZI
