CIT Relay and Switch A11CSQ12VDC12R Power Relay
This power relay features a quick connect terminal shape with a single-pole, double-throw contact arrangement, operating at 12 VDC coil voltage with a maximum current handling capacity of 25 A. Designed for durability and reliability, it is sealed to prevent dust and moisture ingress, making it suitable for automotive, lighting, and industrial applications. The relay has a coil power consumption of 1.2 W, a switching capacity of up to 30A, and can operate within wide temperature ranges from -40°C to +85°C. Its robust copper alloy terminals ensure strong electrical connections and long service life in demanding environments.
CIT Relay and Switch A11CSQ12VDC12R Power Relay Specifications:
- Contact Arrangement: SPDT (Single Pole Double Throw)
- Coil Voltage: 12 VDC
- Coil Resistance: 15.6 Ohms
- Coil Power: 1.2 W
- Maximum Switching Current: 25 A
- Maximum Switching Power: 350 W
- Maximum Switching Voltage: 75 VDC
- Contact Resistance: < 50 milliohms initial
- Insulation Resistance: 100MΩ min. @ 500 VDC
- Dielectric Strength: 2500 V rms coil to contact, 1500 V rms contact to contact
- Electrical Life: 100,000 cycles @ rated load
- Mechanical Life: 10 million cycles
- Operating Temperature: -40°C to +85°C
- Storage Temperature: -40°C to +155°C
- Sealing: Sealed for dust and moisture protection
- Weight: 18.5g
- Dimensions: 23.45 mm x 15.65 mm x 25.80 mm
Buy the CireitIntemiption Reliable Coil Power Relay for Industrial Applications
Purchase the CireitIntemiption power relay online today to enjoy a durable, sealed design capable of handling up to 25 amps at 12 VDC. Ideal for automotive, lighting, and industrial applications, this relay provides reliable switching with a coil power of only 1.2 W. Its robust construction ensures long-lasting performance in demanding environments, with a switch capacity supporting 350 W and 75 VDC. Easy to install with quick connect terminals, it guarantees efficient, secure operation in various electrical systems.
Get CireitIntemiption power relay today—built for precision, sealed protection, and reliable switching performance.
Frequently Asked Questions
Where can I buy CIT Relay and Switch A11CSQ12VDC12R?
You can click on the BUY or RFQ button to purchase A11CSQ12VDC12R from an authorized CIT Relay and Switch distributor.
How do I troubleshoot issues or seek technical support for part A11CSQ12VDC12R?
You can download the A11CSQ12VDC12R datasheet or visit the CIT Relay and Switch website for support.
Who is the manufacturer of A11CSQ12VDC12R?
CIT Relay and Switch
