CIT Relay and Switch A11CSQ12VDC15R Power Relay
This power relay offers a compact, sealed design suitable for automotive and industrial applications. It features a quick connect terminal, SPDT contact configuration, and handles up to 30A switching capacity at 14VDC. The relay operates at 12 VDC with a coil resistance of 15.6 ohms, consuming 1.5 W of power. It provides reliable switching with a maximum switching power of 350W, and its durability is enhanced by a rated electrical life of 100,000 cycles. With key specifications including quick connect terminals, sealing, and a 25A current rating, this relay ensures dependable performance in demanding environments.
CIT Relay and Switch A11CSQ12VDC15R Power Relay Specifications:
- Contact Arrangement: SPDT
- Switching Capacity: up to 30A at 14VDC, maximum switching power 350W
- Coil Voltage: 12 VDC with resistance of 15.6 ohms
- Coil Power: 1.5 W, pull-in voltage 120V, release voltage 96V
- Sealed design, quick connect terminals or PCB pins options
- Electrical life: 100,000 cycles, Mechanical life: 10 million cycles
- Operating temperature: -40°C to +85°C, Storage: -40°C to +155°C
- Insulation Resistance: 100MΩ min. @ 500VDC
- Dielectric Strength: Coil to contact 2500V rms, contact to contact 1500V rms
- Dimensions: 23.45 x 15.65 x 25.8 mm, weight 18.5g
Buy the CIT Relay Series Switch: A11CSQ12VDC15R
Purchase your CIT Relay Series Switch with quick connect terminals today online. This reliable relay features a SPDT contact configuration, handles up to 30A at 14VDC, operates at 12 VDC, and is sealed for durability. Its compact size and lightweight design make it ideal for automotive and industrial applications. With a coil power of 1.5 W and a lifespan of 100,000 cycles, this relay ensures dependable performance in demanding environments. Get yours now and enhance your project’s reliability with this high-quality switching component.
Order your CIT Relay Series Switch with quick connect terminals and 30A capacity today and give your projects the dependable quality they deserve.
Frequently Asked Questions
Where can I buy CIT Relay and Switch A11CSQ12VDC15R?
You can click on the BUY or RFQ button to purchase A11CSQ12VDC15R from an authorized CIT Relay and Switch distributor.
How do I troubleshoot issues or seek technical support for part A11CSQ12VDC15R?
You can download the A11CSQ12VDC15R datasheet or visit the CIT Relay and Switch website for support.
Who is the manufacturer of A11CSQ12VDC15R?
CIT Relay and Switch
