CORNELL DUBILIER AFK107M50F24VTF High Vibration Aluminum Capacitor
The AFK series high vibration aluminum electrolytic capacitors operate from -55°C to +105°C, offering low ESR and long life up to 5000 hours. Designed for filtering and power supply decoupling, they withstand 30 G vibration testing with superior mechanical durability. Available with capacitance values from 10 µF to 6800 µF and rated voltages up to 100 Vdc, these rugged capacitors feature molded plastic surrounds and larger leads for stability. Suitable for power systems exposed to constant motion and vibration, they meet AEC-Q200 standards and exhibit excellent impedance characteristics across a broad temperature range.
CORNELL DUBILIER AFK107M50F24VTF High Vibration Aluminum Capacitor Specifications:
- Capacitance Range: 10 µF to 6800 µF
- Voltage Range: 6.3 Vdc to 100 Vdc
- Operating Temperature Range: -55°C to +105°C
- Leakage Current: 0.01 CV or 3 pA @ +20°C, after two minutes
- Load Life: Up to 5000 hours at +105°C
- Ripple Current: Up to 1800 mA at 100 Vdc
- Impedance Ratio: Z(-55°C)/Z(+20°C) up to 4
- Vibration Resistance: Withstands 30 G acceleration from 5 Hz to 2000 Hz
- Compliance: RoHS, AEC-Q200
- Durability: Designed for power systems with high vibration and motion exposures
Buy the CDE Series AFK_V High Vibration Aluminum Capacitors: AFK107M50F24VTF
Purchase the Cornell Dubilier AFK107M50F24VTF high vibration aluminum capacitor online today. Engineered for demanding environments, it delivers exceptional durability, low ESR, and reliable performance across a broad temperature range. Suitable for power supplies and filtering applications where vibration resistance is crucial, this capacitor withstands 30 G shocks and operates up to 105°C. Its compact design, robust construction, and high ripple current capacity make it an ideal choice for industrial, aerospace, and automotive power systems requiring long-lasting, dependable performance. Order now and ensure your system's stability and longevity.
Get Cornell Dubilier AFK107M50F24VTF today—built for high vibration durability and long life in power systems exposed to constant motion.
