CORNELL DUBILIER ALH105K351A032 AC Filter Capacitors
Aluminum electrolytic capacitors designed for high-frequency applications in harsh environments, these AC filter capacitors are AEC-Q200 qualified with an operating temperature range from -40°C to 105°C. They feature self-healing properties, low loss, and enhanced durability, making them suitable for automotive and industrial use. Available in various voltages up to 450 Vac and capacitance values from 0.22 to 50 uF, they withstand rigorous electrical and mechanical testing, ensuring long service life and reliable performance under demanding conditions.
CORNELL DUBILIER ALH105K351A032 AC Filter Capacitors Specifications:
- Capacitance Range: 0.22 to 50 uF
- Capacitance Tolerance: +10% standard, 5% optional
- Rated Voltage: 160 to 450 Vac
- Operating Temperature Range: -40°C to 105°C (derate voltage 1.35% per °C above 85°C)
- Test Voltage between Terminals @ 25°C: 150% of DC voltage (1.414x Vac) for 10s
- Test Voltage between Terminals and Case @ 25°C: 3 kVac @ 50/60 Hz for 10s
- Insulation Resistance: 230,000 MΩ×pF @ 100 Vdc after 1 min
- Life Expectancy: 100,000 hours at 70°C hot spot and rated voltage
- Construction: Plastic case UL94V-0, dry resin UL94V-0, tin-plated copper terminals
- RoHS compliant, IEC 61071, AEC-Q200 qualified
- Dimensions vary according to capacitance and voltage rating
- Maximum RMS Current varies by model, detailed in ratings table
Buy the CDE Series ALH AC Filter Capacitors: ALH105K351A032
Enhance your electrical systems with our high-quality AC filter capacitors designed for harsh environments. Rated up to 450 Vac, these durable, low-loss, self-healing capacitors meet AEC-Q200 standards, ensuring long-lasting performance in automotive, industrial, and high-frequency applications. Their robust construction withstands extreme temperatures and rigorous testing, making them ideal for demanding settings. Purchase online today and benefit from reliable, high-performance filtering components that improve electrical stability and improve system longevity, backed by trusted quality standards and quick delivery.
Order your CDE Series ALH AC filter capacitor ALH105K351A032 today and give your industrial and automotive projects the dependable high-frequency filtering performance they deserve.
