CORNELL DUBILIER CD42FD473FO3F mica capacitor
The CD42 series standard dipped mica capacitor is an ideal choice for precise timing and applications requiring close tolerance. It is widely available through distribution and meets the EIA RS153B dimensional specifications. The capacitor supports a minimum pulse voltage change rate of 100,000 V/μs. It is a non-flammable unit that complies with IEC 695-2-2 standards. Designed for high stability over a broad temperature range, it is suitable for timing, high-frequency, and RF applications, with a capacitance range from 1 pF to 91,000 pF and rated voltages up to 2500 Vdc. It features epoxy case, copper clad steel terminals, and RoHS compliance.
CORNELL DUBILIER CD42FD473FO3F mica capacitor Specifications:
- Capacitance Range: 1 pF to 91,000 pF
- Rated Voltage: 100 Vdc to 2500 Vdc
- Operating Temperature Range: -55°C to +150°C
- Dimensions meet EIA RS153B specifications
- Pulse Voltage Capability: Minimum 100,000 V/μs dV/dt
- Dielectric Strength Test: 200% of rated voltage
- RoHS Compliant
- Case Material: Epoxy
- Terminal Material: Copper clad steel, nickel undercoat, 100% tin finish
- Temperature Tolerance: +/−0.5% to +5%
- Vibration Grade: MIL-STD-202, Test Method 204
Buy the Buy CDE Mica Capacitors Part Number CD42FD473FO3F Online
Order the reliable CDE mica capacitor CD42FD473FO3F online today. Engineered for precise timing, close tolerance, and high pulse voltage support up to 2500 Vdc. Its robust epoxy case and copper terminals provide durability and stability over a wide temperature range from -55°C to +150°C. Ideal for RF and timing applications, it meets industry standards like EIA RS153B and IEC 695-2-2 without flammability concerns. Purchase now to ensure high-performance circuit stability and long-lasting operation.
Get CDE CD42FD473FO3F today—built for precise timing and reliable high-frequency performance.
Frequently Asked Questions
Where can I buy CORNELL DUBILIER CD42FD473FO3F?
You can click on the BUY or RFQ button to purchase CD42FD473FO3F from an authorized CORNELL DUBILIER distributor.
How do I troubleshoot issues or seek technical support for part CD42FD473FO3F?
You can download the CD42FD473FO3F datasheet or visit the CORNELL DUBILIER website for support.
Who is the manufacturer of CD42FD473FO3F?
CORNELL DUBILIER
