CORNELL DUBILIER SLPX472M050A7P3 Aluminum Electrolytic Capacitor
The SLPX series is a cost-effective snap-in aluminum electrolytic capacitor designed for 85°C operation with a 3000-hour lifespan. It offers high ripple current capability and compact size, making it ideal for switching power supplies and filtering applications. Available in diameters from 22 mm to 35 mm with lead spacing of 10 mm, these capacitors support voltage ratings from 10 Vdc to 450 Vdc and capacitance values up to 82,000 μF. They provide reliable performance with low ESR, good frequency response, and long shelf life, meeting RoHS standards.
CORNELL DUBILIER SLPX472M050A7P3 Aluminum Electrolytic Capacitor Specifications:
- Temperature Range: -40°C to +85°C
- Rated Voltage Range: 10 Vdc to 450 Vdc
- Capacitance Range: 68 μF to 82,000 μF
- Capacitance Tolerance: +20%
- Ripple Current Multipliers: varies with temperature and frequency, supporting high ripple current
- Leakage Current: <3 VCVpA at 5 minutes
- Impedance Ratio: <10 at 10Vdc, <8 at 16-50Vdc, <4 at 63-100Vdc, <3 at 150-450Vdc, at 25°C
- Endurance Life: 3000 hours at 85°C
- Shelf Life: 1000 hours at 85°C with capacitance +15%, ESR <150% of limit
- Vibration: 10 Hz to 55 Hz, 0.06" amplitude, 2g max for 2 hours in each plane
- RoHS Compliant
Buy the CDE Series Snap-In Aluminum Electrolytic Capacitor: SLPX472M050A7P3
Procure the CDE Series aluminum electrolytic capacitor today for your DC filtering and power supply needs. With a lifespan of 3000 hours at 85°C, high ripple current support, and a compact, versatile design, this capacitor is ideal for demanding electronic applications. It features a capacitance range up to 82,000 μF, voltage ratings from 10 Vdc to 450 Vdc, and low ESR for enhanced performance. Fast online ordering guarantees reliable supply, enabling efficient and durable project outcomes with proven long-term stability.
Order your CDE Series Snap-In Aluminum Electrolytic Capacitor with 82,000 μF capacitance today and ensure your power supply projects deliver long-lasting reliability.
Frequently Asked Questions
Where can I buy CORNELL DUBILIER SLPX472M050A7P3?
You can click on the BUY or RFQ button to purchase SLPX472M050A7P3 from an authorized CORNELL DUBILIER distributor.
How do I troubleshoot issues or seek technical support for part SLPX472M050A7P3?
You can download the SLPX472M050A7P3 datasheet or visit the CORNELL DUBILIER website for support.
Who is the manufacturer of SLPX472M050A7P3?
CORNELL DUBILIER
