CROMPTON---TE-CONNECTIVITY 5SFT201 Current Transformer
The 5SFT-201 is a 5-volt-ampere current transformer with a 200:5 current ratio and an accuracy of ±1% at 60Hz. It features brass terminal studs with a No. 8-32 UNC thread, along with flat washers, lock washers, and nuts for secure connections. Designed for use with ammeters, wattmeters, and for cross-current compensation, this transformer is ideal for test, measurement, and industrial applications. It is equipped with UL and CSA approvals, ensuring safety and compliance in various environments.
CROMPTON---TE-CONNECTIVITY 5SFT201 Current Transformer Specifications:
- Model: 5SFT-201
- Window Diameter: 1.56 inches
- Open Slots: 0.21 x 0.31 inches
- Current Ratio: 200:5
- Accuracy: ±1% at 60Hz
- Frequency Range: 50-400Hz
- Insulation Level: 600 Volts, 10kV BIL full wave
- Leads: UL 1015 105°C, CSA approved, 24 inches long
- Terminals: Brass studs No. 8-32 UNC with flat washer, lock washer, nut
- Mounting: Bracket kit available for Model SSHT
- Weight: approximately 1.0 lb
- Certifications: UL 257877, CSA 223647
Buy the Buy Innovative Current Transformer Part Number 5SFT201 Online
Order the 5SFT-201 current transformer online today and enhance your measurement setup with precise 200:5 current ratio, robust brass terminals, and UL & CSA approvals. Perfect for industrial applications, wattmeters, and cross-current compensation, this transformer ensures quality and reliability. Its compact design and easy mounting options make installation straightforward, while the 60Hz accuracy guarantees precise readings. Purchasing online allows quick delivery and access to certified, high-performance measurement solutions for your testing and industrial needs.
Buy 5SFT-201 current transformer now and experience reliable measurement accuracy with durable brass terminals for industrial and test environments.
