CUI Inc PCN1S24S15S DC-DC Converter
The CUI Inc PCN1-S24-S15-S is a compact and efficient DC-DC converter designed for a variety of industrial applications. This converter provides an isolated output in a SIP package, offering nominal input voltages of 24Vdc and a 15Vdc output. It delivers up to 1W of power with efficiency reaching up to 83%, making it suitable for space-constrained designs. Key features include low ripple and noise, a wide operating temperature range (-40 to 100°C), and 1,500 Vdc isolation voltage. A 2.2 µF or 4.7 µF ceramic capacitor is recommended for input voltage stress reduction.
CUI Inc PCN1S24S15S DC-DC Converter Specifications:
- input voltage range: 21.6~26.4 Vdc
- output voltage: 15 Vdc
- output current: 67 mA
- output power: 1 W
- ripple and noise: 1 mVp-p (at full load, nominal input, 20 MHz bandwidth oscilloscope, with a 0.33 µF ceramic capacitor on the output)
- efficiency: 81%
- isolation voltage: 1,500 Vdc
- isolation resistance: 1,000 MΩ
- isolation capacitance: 10 pF
- operating temperature: -40 to 100 °C
- storage temperature: -55 to 125 °C
- voltage accuracy: ±3.0%
- line regulation: ±1.2%
- load regulation: ±10%
- switching frequency: 75 kHz (24 Vdc input models)
- temperature coefficient: ±0.05 %/°C
- short circuit protection: 1 s
- mtbf: 1,500,000 hours
- rohs_compliant: Yes
- case material: Non-conductive black plastic
- weight: 2.7 g (24 Vdc input models)
