CUI Inc PCN1S24S5S DC-DC Converter
The CUI Inc PCN1-S24-S5-S is a compact and efficient DC-DC converter designed for a variety of industrial applications. It utilizes an isolated output and is housed in a standard SIP package, making it easy to integrate into existing designs. The converter offers flexible input voltage options (5V, 12V, or 24Vdc) and supports both single and dual output configurations. With efficiencies reaching up to 83%, the PCN1-S24-S5-S provides reliable power conversion while minimizing energy loss. It's suitable for applications requiring a stable and isolated power supply in a small form factor.
CUI Inc PCN1S24S5S DC-DC Converter Specifications:
- input voltage (typ): 24 Vdc
- input voltage range: 21.6~26.4 Vdc
- output voltage: 5 Vdc
- output current (max): 200 mA
- output power (max): 1 W
- ripple & noise (max): 1 mVp-p
- efficiency (typ): 80%
- operating temperature: -40 to 100°C
- isolation voltage: 1,500 Vdc
- isolation resistance: 1,000 MΩ
- isolation capacitance: 10 pF
- surge voltage (max): 30 Vdc
- current (max): 50 mA
- switching frequency: 75 kHz
- voltage accuracy: ±3.0%
- line regulation: ±1.2%
- load regulation: ±10%
- temperature coefficient: ±0.05 %/°C
- short circuit protection: 1 s
- mtbf: 1,500,000 hours
- rohs_compliant: Yes
- case material: Non-conductive black plastic
- weight: 2.7 g
Buy the PCN1-S24-S5-S CUI Inc DC-DC Converter | myMectronic
Purchase the CUI Inc PCN1-S24-S5-S DC-DC converter securely and reliably online.
Buy Now
Frequently Asked Questions
Where can I buy CUI Inc PCN1S24S5S?
You can click on the BUY or RFQ button to purchase PCN1S24S5S from an authorized CUI Inc distributor.
How do I troubleshoot issues or seek technical support for part PCN1S24S5S?
You can download the PCN1S24S5S datasheet or visit the CUI Inc website for support.
Who is the manufacturer of PCN1S24S5S?
CUI Inc
