Carling Technologies EA2B0248102DAEB Hydraulic-Magnetic Circuit Breaker
The E-Series hydraulic-magnetic circuit breaker from CARLING TECHNOLOGIES is engineered for demanding high-current and high-voltage applications. Qualified to meet agency approval standards, these breakers provide robust branch circuit protection or serve as a supplementary protector. Available in configurations ranging from one to six poles, they are rated up to 125 amps and 600VAC or 125VDC, with a maximum interrupting current of 10,000 amps. Typical applications include renewable energy systems, military equipment, industrial automation, generators, commercial food service, and environments requiring high voltage/current protection. The breakers are designed to meet MIL PRF-55629 & MIL-STD-202G specifications, ensuring shock, vibration, moisture, and thermal shock resistance.
Carling Technologies EA2B0248102DAEB Hydraulic-Magnetic Circuit Breaker Specifications:
- Voltage: 600VAC, 125VDC
- Current Ratings: 0.100 - 100 Amps
- Interrupting Current: 10,000 Amps
- Poles: 1-6
- Auxiliary Switch Rating: SPDT; 10.1A 250VAC, 1.0A 65VDC, 0.5A 80VDC, 0.1A 125VAC
- Insulation Resistance: Minimum of 100 Megohms at 500 VDC
- Dielectric Strength: 2200 V 50/60 Hz
- Operating Temperature: -40° C to +85° C
- Endurance: 10,000 ON-OFF operations
- Shock Resistance: Withstands 100 Gs, 6ms
- Vibration Resistance: Withstands 0.060” excursion from 10-55 Hz
- Moisture Resistance: Method 106D
- Salt Spray Resistance: Method 101, Condition A
Buy the EA2-B0-24-810-2DA-EB CARLING TECHNOLOGIES Hydraulic-Magnetic Circuit Breaker | myMectronic
Purchase the CARLING TECHNOLOGIES EA2-B0-24-810-2DA-EB Hydraulic-Magnetic Circuit Breaker securely and conveniently online.
Buy Now
Frequently Asked Questions
Where can I buy Carling Technologies EA2B0248102DAEB?
You can click on the BUY or RFQ button to purchase EA2B0248102DAEB from an authorized Carling Technologies distributor.
How do I troubleshoot issues or seek technical support for part EA2B0248102DAEB?
You can download the EA2B0248102DAEB datasheet or visit the Carling Technologies website for support.
Who is the manufacturer of EA2B0248102DAEB?
Carling Technologies
