Carling Technologies LC301 Rocker Switch
The CARLING TECHNOLOGIES LC3-01 is a versatile sealed rocker switch designed for a wide range of industrial applications. It offers countless unique options, including choices for ratings, colors, illuminations, and laser-etched legends. These single or double-pole switches feature a broad choice of actuator styles, colors, and lenses, making them suitable for diverse needs. The switch is sealed to IP67, making it ideal for above-panel components, and utilizes roller pins to increase the operating temperature range. With various terminal options and a robust design, the LC3-01 provides reliable performance in demanding environments.
Carling Technologies LC301 Rocker Switch Specifications:
- Poles: 1-2
- Amps: .4-20
- VAC: 125-250
- VDAC: 12-24
- Contact Rating: 4VA @ 24VDC (MAX) resistive
- Sealing: IP67
- Mounting Hole: 1.734 x .867 in [44.0mm x 22.0mm]
- Panel Thickness Range: Acceptable Panel Thickness .030 to .156 (.76mm to 3.96mm)
- Actuator Travel: 26° (13° from center)
- Terminal Options: .250 or .187 tabs with up to 12 terminal options
- Material: Base: Nylon 66 GF rated to 85°C with a flammability rating of 94V0; Actuator: Thermoplastic polycarbonate with a hard Nylon 66 thermoplastic surface overlay; Lens: Polycarbonate rated at 100°C
- Operating Temperature: -40°C to + 85°C
- Dielectric Strength: 1250 Volts RMS between pole to pole; 3750 Volts RMS between live parts and accessible surfaces
- Insulation Resistance: 50 Megohms
- Initial Contact Resistance: 10 milliohms max. @ 4 VDC
- Life: Up to 100,000 cycles (momentary); 50,000 cycles (momentary circuit and load dependent)
Buy the LC3-01 CARLING TECHNOLOGIES Rocker Switch | myMectronic
Purchase the CARLING TECHNOLOGIES LC3-01 Rocker Switch securely and efficiently online.
Buy Now
Frequently Asked Questions
Where can I buy Carling Technologies LC301?
You can click on the BUY or RFQ button to purchase LC301 from an authorized Carling Technologies distributor.
How do I troubleshoot issues or seek technical support for part LC301?
You can download the LC301 datasheet or visit the Carling Technologies website for support.
Who is the manufacturer of LC301?
Carling Technologies
