Carling Technologies LME01 Rocker Switch
The CARLING TECHNOLOGIES LME-01 L-Series rocker switch provides a flexible and reliable solution for various industrial applications, including construction machinery, agricultural equipment, and on-highway transportation. Its neatly proportioned design fits into a standard mounting hole, and it offers numerous customization options for ratings, circuits, colors, and illumination. The switch is IP67 certified, withstands temperatures from -40°C to +85°C, and is resistant to vibration, shock, moisture, and salt spray. Available with .250 TAB or .187 TAB termination options, the LME-01 is a robust and adaptable choice for demanding environments.
Carling Technologies LME01 Rocker Switch Specifications:
- Contact Rating: .4VA @ 24VDC (MAX) resistive 15 amps, 125VAC 10 amps, 250VAC 20 amps, 4-14VDC 15 amps, 15-28VDC
- Dielectric Strength: 1250 Volts RMS between pole to pole 3750 Volts RMS between live parts and accessible surfaces
- Insulation Resistance: 50 Megaohms Initial
- Contact Resistance: 10 milliohms max. @ 4VDC
- Life: 100,000 cycles maintained, 50,000 cycles momentary
- Material: Brass or copper/silver plate
- Terminals: 3/16” (4.76mm) & 1/4” (6.3mm)
- Mechanical Endurance: 250,000 cycles minimum
- Lighted Incandescent: rated 10,000 hours
- LED: rated 100,000 hours
- Seals: Rocker, base & bracket are sealed
- Base Material: Nylon 66 GF rated to 85°C with a flammability rating of 94V0
- Rocker Material: Nylon 66 Reinforced, rated to 105°C
- Lens Material: Polycarbonate rated at 100°C
- Bracket Material: Nylon Zytel
- Actuator Travel (2 position): 26°
- Actuator Travel (3 positions): 13° from center
- IP Rating: IP67
- Corrosion Resistance: Mixed Flowing Gas MFG Class III per ASTM B-827 & B-845, Method H, with 3 years exposure
- Operating Temperature: -40°C to + 85°C
- Mounting Hole: 1.734 x .867 [44.0mm x 22.0mm]
- Panel Thickness Range: .030 to .156 (.76mm to 3.96mm)
