Crydom D2410T Solid State Relay
The Crydom D2410T is a robust panel mount solid state relay (SSR) engineered for demanding industrial applications. It provides reliable switching for loads requiring currents from 10A to 125A at voltages ranging from 24 to 280 VAC. Key features include SCR output for heavy loads, selectable zero voltage or instantaneous turn-on, and comprehensive approvals (UL/CSA/VDE, CE). The improved SEMS screw and washer design, along with the redesigned housing with anti-rotation barriers, enhance performance and durability. This SSR is suitable for applications requiring AC or DC control and benefits from a direct bond copper substrate for efficient heat dissipation. Its epoxy-free design and Level 3 EMC compliance further contribute to its suitability for sensitive environments.
Crydom D2410T Solid State Relay Specifications:
- Ratings: 10A to 125A @ 24-280 VAC
- Output: SCR output
- Turn-on: Zero voltage or instantaneous turn-on
- Approvals: UL/CSA/VDE Approved, CE Compliant to EN60950-1
- Control: AC or DC control
- Substrate: Direct bond copper substrate
- EMC: Compliant to Level 3
- Termination: Screw
- Overvoltage Protection: Included
- Ambient Operating Temperature Range: -40 to 80°C
- Ambient Storage Temperature Range: -40 to 125°C
- Weight: 2.6 oz (74.9g)
- Housing Material: UL 94 V-0
- Baseplate Material: Aluminum
- Input Terminal Screw Torque Range: 13-15 /1.5-1.7 in-lb/Nm
- Load Terminal Screw Torque Range: 18-20 / 2.0-2.2 in-lb/Nm
- SSR Mounting Screw Torque Range: 18-20 / 2.0-2.2 in-lb/Nm
- Input/Load Terminal Screw Thread Size: #6-32 UNC / #8-32 UNC
- Humidity: 93% non-condensing
- MTBF: 11,641,553 hours (1,328 years) at 40°C
- Operating Voltage: 24-280 Vrms
- Transient Overvoltage: 600 Vpk
- Leakage Current: 1 mArms
- dv/dt: 500 V/µsec
- Load Current: 10-125 Arms
- Minimum Load Current: 150-250 mArms
- Surge Current: 115/120 - 1670/1750 Apk
- Voltage Drop: 1.15 Vrms
- Junction to Case Resistance: 0.22-1.03 °C/W
- I²t: 66/60 - 13950/12709 A²sec
- Power Factor: 0.5
- Control Voltage Range: 3-32 VDC, 90-280 Vrms, 18-36 Vrms
- Reverse Voltage: -32 VDC
- Turn-On Voltage: 3.0 VDC, 90 Vrms, 18 Vrms
- Turn-Off Voltage: 1.0 VDC, 10 Vrms, 4 Vrms
- Input Current (min): 7 mA
- Input Current (max): 20 mA
- Input Impedance: Current Regulated
- Turn-On Time: 1/2 Cycle, 20 msec
- Turn-Off Time: 1/2 Cycle, 30 msec
- Dielectric Strength: 4000 Vrms
- Insulation Resistance: 109 Ohm
- Capacitance: 8 pF
