DIALIGHT 6051211110F Snap-in LED Indicator
The DIALIGHT 605 series snap-in LED indicators are designed for a wide range of applications, including power indication, status monitoring, and warning systems. These indicators feature a long operational life, low power consumption, and generate minimal heat. Constructed with a chrome-plated brass housing, they offer durability and a professional appearance. The 605-1211-110F variant specifically provides a green LED with protruding configuration, making it suitable for applications requiring clear visual signaling. They are RoHS compliant and offer a reliable solution for industrial and commercial environments.
DIALIGHT 6051211110F Snap-in LED Indicator Specifications:
- Mounting Hole Size: 0.249 - 0.252 inches (6.32 - 6.40 mm)
- Maximum Panel Thickness: 0.138 inches (3.5 mm)
- Operating Voltage: 2 VDC
- Operating Temperature: -25ºC to +85ºC
- Storage Temperature: -25ºC to +100ºC
- Electrical Connection: Through leads
- Leads: Straight leads
- Housing Material: Chrome plated brass
- LED Positions: Protruding
- Color: Green
- Current: 15 mA
- Typical Intensity: 72 mcd
- RoHS Compliant: Yes
