DIGILENT 410267 Datasheet & Stock
The Pmod STEP is a demonstration board designed to facilitate driving a stepper motor using any host system equipped with a 12-pin Pmod connector. It features a four-channel push-pull driver capable of delivering up to 600mA per channel. The board includes eight digital I/O signals on header J1, each connected to LEDs that display their current states. Four signals are used to control the stepper motor driver, which can be powered either from the microcontroller's Vcc or an external power supply via a screw terminal. The device provides locking, keyed headers compatible with both 4-pin and 6-pin stepper motors, signal headers for easy digital I/O monitoring, and status/power LEDs. It is suitable for applications in testing, measurement, and industrial environments.
Frequently Asked Questions
Where can I buy DIGILENT 410267?
You can click on the BUY or RFQ button to purchase 410267 from an authorized DIGILENT distributor.
How do I troubleshoot issues or seek technical support for part 410267?
You can download the 410267 datasheet or visit the DIGILENT website for support.
Who is the manufacturer of 410267?
DIGILENT
