E-SWITCH 800USP8P1A1M7RE Pushbutton Switch
The 800U Series Pushbutton Switch is a robust, anti-vandal switch designed for reliability in demanding environments. It features SPDT and DPDT circuit functions, a mechanical life of 40,000 cycles, and an electrical rating of 0.4VA at 20V. With IP67 sealing, it offers durability against dust and water. The switch includes multiple termination options, color-coded contact caps, and an actuation force of 250 gf. Its compact size and variety of configurations make it suitable for industrial, security, and control applications.
E-SWITCH 800USP8P1A1M7RE Pushbutton Switch Specifications:
- Electrical Rating: 0.4VA @ 20V Max (AC or DC)
- Mechanical Life: 40,000 Cycles
- Electrical Life: 6,000 Cycles
- Contact Resistance: 100mΩ initial
- Insulation Resistance: 500MΩ Min.
- Dielectric Strength: 500VAC
- Operating/Storage Temperature: -30°C to 85°C
- Travel: 1.0mm
- Circuit Function: SPDT, DPDT
- Actuation Force: 250 gf
- Dimensions: Compact size with various termination and cap options
- Sealed IP67 rated for dust and water resistance
Buy the Buy Brand Name Pushbutton Switch Part Number 800USP8P1A1M7RE Online
Purchase the Brand Name 800USP8P1A1M7RE pushbutton switch online today for reliable operation in industrial and security applications. This compact, IP67-rated switch offers SPDT and DPDT functions, a mechanical life of 40,000 cycles, and a sealed design to resist dust and water. It features multiple terminal options, color-coded caps for quick identification, and an actuation force of 250 gf. Perfect for demanding environments, this switch ensures durability and consistent performance in demanding control, automation, and security setups.
Order your Brand Name Series800USP8P1A1M7RE durable pushbutton switch today and enhance your control systems with dependable, sealed, anti-vandal operation.
Frequently Asked Questions
Where can I buy E-SWITCH 800USP8P1A1M7RE?
You can click on the BUY or RFQ button to purchase 800USP8P1A1M7RE from an authorized E-SWITCH distributor.
How do I troubleshoot issues or seek technical support for part 800USP8P1A1M7RE?
You can download the 800USP8P1A1M7RE datasheet or visit the E-SWITCH website for support.
Who is the manufacturer of 800USP8P1A1M7RE?
E-SWITCH
