E-SWITCH PP27U12B2 Industrial Toggle Switch
The product is a versatile toggle switch designed for industrial and control applications with high ratings and multiple actuator options. It features dual positions, multiple terminal configurations, and robust construction suitable for demanding environments. The switch supports ON-ON, ON-OFF, and other functions, with electrical ratings up to 16A 125VAC and 10A 277VAC. It has a panel cutout size of 13.5mm x 36mm, operating temperature from 0°C to 85°C, and an electrical life of 6,000 cycles, ensuring reliable operation in various applications.
E-SWITCH PP27U12B2 Industrial Toggle Switch Specifications:
- Electrical Rating: 10A 277VAC, 16A 125VAC, 1HP 125/250VAC
- Panel Cutout: 13.5mm x 36mm
- Operating Temperature: 0°C to 85°C
- Electrical Life: 6,000 Cycles
- Mechanical Life: 50,000 Cycles
- Contact Resistance: 10mΩ Max
- Insulation Resistance: 10MO Min
- Actuator Options: Straight, Push-Pull, Short, with various sizes
- Terminal Options: Vertical Tabs, 4.8mm x 0.8mm, 6.3mm x 0.8mm
- Switch Function: DPDT, On-On or On-Off, With high ratings and UL approvals
- Dimensions vary based on actuator and terminal configurations
Buy the Industrial Control Switch Series PP27U12B2: PP27U12B2
Purchase the industrial toggle switch series PP27U12B2 online today and benefit from high electrical ratings, durable construction, and versatile actuator options. Ideal for demanding control applications, this switch offers up to 16A capacity at 125VAC, a compact panel cutout of 13.5mm x 36mm, and a proven electrical life of 6,000 cycles. Its robust build ensures reliable operation across various industrial environments, making it an excellent choice for engineers and maintenance professionals seeking quality control components. Order now for fast delivery and seamless integration into your systems.
Buy industrial toggle switch series PP27U12B2 now and experience unmatched reliability and performance in your control panels.
Frequently Asked Questions
Where can I buy E-SWITCH PP27U12B2?
You can click on the BUY or RFQ button to purchase PP27U12B2 from an authorized E-SWITCH distributor.
How do I troubleshoot issues or seek technical support for part PP27U12B2?
You can download the PP27U12B2 datasheet or visit the E-SWITCH website for support.
Who is the manufacturer of PP27U12B2?
E-SWITCH
