E-SWITCH PV6H240SS331 industrial toggle switch
The PV6H240SS331 is a stainless steel, SPDT toggle switch with a green illumination feature, rated at 2A 48VDC. It features a flat actuator with a machine finish, suitable for panel mounting with a maximum panel thickness of 12mm. The switch has a contact resistance of 50mΩ at 1A 12VDC, an electrical life of 200,000 cycles at full load, and insulation resistance of 1,000 MΩ minimum. Operating temperature ranges from -20°C to 55°C, with a travel distance of 1.8mm and an illumination rating of 20mA 2.8V. Hardware includes an O-ring and hex nut for secure installation.
E-SWITCH PV6H240SS331 industrial toggle switch Specifications:
- Switch Function: SPDT
- Contact Material: Silver plated
- Rating: 2A 48VDC
- Electrical Life: 200,000 cycles at full load
- Insulation Resistance: 1,000 MΩ minimum
- Dielectric Strength: 2,000 VAC for 1 minute
- Contact Resistance: 50mΩ at 1A 12VDC
- Operating Temp: -20°C to 55°C
- Travel: 1.8mm
- Illumination Color: Green
- Illumination Rating: 20mA 2.8V
- Material: Stainless Steel
- Body Finish: Machine finish
- Panel Cutout: 16.50mm ± 0.50mm
- Maximum Panel Thickness: 12mm
- Hardware: O-ring and hex nut included
Buy the Generic PV6H240SS331 – Reliable Industrial Toggle Switch for Industrial Applications
Enhance your industrial equipment with the reliable stainless steel toggle switch PV6H240SS331, featuring green illumination and a rated capacity of 2A 48VDC. Perfect for panel mounting applications, it offers a durable flat actuator with a machine finish and secure hardware including an O-ring and hex nut. With a travel of 1.8mm, a long electrical life of 200,000 cycles, and excellent insulation resistance, this switch ensures safe and stable operation across a wide temperature range. Get yours online today for dependable performance!
Order your Generic Series PV6H240SS331 toggle switch today and give your projects the dependable quality they deserve with robust stainless steel construction.
Frequently Asked Questions
Where can I buy E-SWITCH PV6H240SS331?
You can click on the BUY or RFQ button to purchase PV6H240SS331 from an authorized E-SWITCH distributor.
How do I troubleshoot issues or seek technical support for part PV6H240SS331?
You can download the PV6H240SS331 datasheet or visit the E-SWITCH website for support.
Who is the manufacturer of PV6H240SS331?
E-SWITCH
