E-SWITCH PVS7F2HSS331M01 Anti-Vandal Switch
The PVS7 series anti-vandal switch is a robust, IP65-rated switch ideal for industrial applications. It features a stainless steel body, 22mm diameter panel cutout, and multiple actuation options including illuminated and non-illuminated versions. The switch supports both SPDT and DPDT contact arrangements, with optional RGB LED illumination for enhanced visibility. Its rugged construction ensures durability, while soldered wire leads provide reliable electrical connections. Suitable for panel thicknesses of 1-11mm, it is designed for demanding environments requiring vandal-resistant, high-performance switches.
E-SWITCH PVS7F2HSS331M01 Anti-Vandal Switch Specifications:
- Electrical Rating: 2A, 24VDC
- Electrical Life: 50,000 Cycles
- Contact Resistance: 50mQ Max.
- Insulation Resistance: 1000 MO Min.
- Dielectric Strength: 2,000VAC
- Operating/Storage Temperature: -20°C to 55°C
- Travel: 2.50mm
- Moisture Protection: IP65
- Contact Arrangement: SPDT, DPDT
- Actuation Force: 4 N
- Panel Thickness: 1-11mm
- Mounting Nut Torque: 5-14Nm
Buy the Vanguard Switch PVS7F2HSS331M01 – Reliable Anti-Vandal Switch for Industrial Applications
Discover the highly durable and IP65-rated anti-vandal switch perfect for demanding industrial environments. The PVS7 series features a stainless steel body, 22mm panel cutout, and versatile contact options including SPDT and DPDT configurations. Optional illuminated versions with RGB LEDs enhance visibility, and soldered wire leads provide reliable electrical connections. Designed for panel thicknesses of 1-11mm, this switch offers exceptional resistance to vandalism and harsh conditions. Elevate your equipment reliability by purchasing online today for fast delivery and superior performance.
Order your Vanguard Series PVS7F2HSS331M01 today and ensure your industrial projects benefit from the dependable, vandal-resistant switch performance.
