E-SWITCH RB242D1000116 Vandal-Resistant Rocker Switch
The RB2 Series Rocker Switches are high-quality, reliable, vandal-resistant switches designed for industrial and panel applications. They offer various mounting options, including optional dust and water protection caps, and support multiple terminal, actuator, and illumination configurations. Rated for up to 16A 125VAC and 20A 125VAC, these switches feature IP54 ingress protection, a dielectric strength of 1,500VAC, and an operating temperature range of -20°C to 65°C. Suitable for controlling electrical circuits with multiple circuit positions and function options.
E-SWITCH RB242D1000116 Vandal-Resistant Rocker Switch Specifications:
- Electrical Rating: 16A 125VAC T85, 20A 125VAC T105, 16A 250VAC T85, 20A 250VAC T105
- Ingress Protection: IP54 with optional silicone cap
- Dielectric Strength: 1,500VAC for 1 min.
- Operating Temperature: -20°C to 65°C
- Contact Resistance: 35mΩ Max at 50VAC
- Insulation Resistance: 100MΩ Min at 500VDC
- Mechanical Life: 10,000 cycles
- Panel Thickness Compatibility: 0.75 - 3.00 mm with tolerance ±0.1 mm
- Body Dimensions: Approximately 22 mm x 30 mm, various actuator styles
- Electrical and mechanical ratings vary with specific models and configurations
- Available with illumination, 2 or 3 position functions, and custom markings
Buy the RB2 Series Rocker Switch: RB242D1000116
Order the RB2 Series vandal-resistant rocker switches online now for robust panel control solutions. Designed for industrial environments, these switches feature IP54 ingress protection, multiple circuit configurations, and reliable electrical ratings up to 20A. Easy to install with standard cutout sizes, they offer illumination options and optional dust and water protection caps. Ensure your control panels meet high durability standards and operate efficiently with these versatile switches. Purchase online today for fast delivery and exceptional quality.
Get RB2 Series Rocker Switches today—built for durability, flexibility, and reliable electrical performance.
Frequently Asked Questions
Where can I buy E-SWITCH RB242D1000116?
You can click on the BUY or RFQ button to purchase RB242D1000116 from an authorized E-SWITCH distributor.
How do I troubleshoot issues or seek technical support for part RB242D1000116?
You can download the RB242D1000116 datasheet or visit the E-SWITCH website for support.
Who is the manufacturer of RB242D1000116?
E-SWITCH
