E-SWITCH RBW2ABLKRILFF1 Vandal-Resistant Switch
The RBW2 series is a range of waterproof, vandal-resistant switches suitable for various industrial and outdoor applications. Featuring IP66 ingress protection, these switches offer full illumination options and are UL-approved up to 1/3 HP, ensuring reliable operation in harsh environments. The switches come in configurations including DPST, DPDT, and Off-On functions, with panel cutouts of 22mm x 30mm. They are designed for durability with an operating temperature range of -20°C to 85°C and electrical ratings up to 125VAC and 250VAC. Suitable for control panels, machinery, and outdoor equipment.
E-SWITCH RBW2ABLKRILFF1 Vandal-Resistant Switch Specifications:
- Electrical Rating: 16(16)A 125VAC 5E4 T85 [cURus]
- 1/3HP 125VAC IP66 [cURus]
- 10(10)A 250VAC 5E4 T85 [VDE]
- Ingress Protection: IP66
- Operating Temperature: -20°C to 85°C
- Panel Cutout: 22mm x 30mm
- Contact Resistance: <30mΩ Max.
- Insulation Resistance: 500MΩ Min. at 500VDC
- Dielectric Strength: 1000VAC for 1 Minute
- Mechanical Life: 10,000 Cycles
- Function: DPST, Off-On, DPDT, On-On
- Body Color: Black, White, Red, Full Illumination options available
- Actuator Color: Black, White, Red, Green, Yellow, Blue
- Illumination: Full optional, various LED colors
- Panel Thickness Compatibility: 25.5/50.0mm, 30.375mm
- Marking and termination options: A-Dot, F-6.3mm Tab, Neon, Incandescent, No Marking
Buy the E-switch Series RBW2 Switches: RBW2ABLKRILFF1
Discover the dependable performance of the vandal-resistant waterproof switches from the RBW2 series. Featuring full illumination options, UL approval, and IP66 ingress protection, these switches are ideal for outdoor and industrial environments. Designed with durable materials and a panel cutout of 22mm x 30mm, they support multiple configurations including DPST and DPDT functions. Their operating temperature range from -20°C to 85°C makes them suitable for harsh conditions. Purchase online today for reliable control components for your demanding applications.
Order your E-switch Series RBW2 illuminated vandal-resistant switch today and secure reliable control for your outdoor and industrial projects.
Frequently Asked Questions
Where can I buy E-SWITCH RBW2ABLKRILFF1?
You can click on the BUY or RFQ button to purchase RBW2ABLKRILFF1 from an authorized E-SWITCH distributor.
How do I troubleshoot issues or seek technical support for part RBW2ABLKRILFF1?
You can download the RBW2ABLKRILFF1 datasheet or visit the E-SWITCH website for support.
Who is the manufacturer of RBW2ABLKRILFF1?
E-SWITCH
