E-SWITCH RR3112DBLKBLKNAF0 Rocker Switch
The RR3112D rocker switch offers reliable operation with a contact rating of 16A at 125VAC and 10A at 250VAC. It features a mechanical life expectancy of 20,000 cycles and an electrical lifespan of 6,000 cycles. The switch provides low contact resistance of 50 milliohms initially, high insulation resistance of 100 megaohms at 500V DC, and a dielectric strength of at least 1,500V for one minute. Designed for easy operation, it suits industrial and visual applications, ensuring durability and safety across various markets. The switch is rated for temperatures from 0°C to 65°C and supports multiple configurations including SPST, SPOT, and ON-OFF functionalities, with optional neon or LED indicators for enhanced visibility and control.
E-SWITCH RR3112DBLKBLKNAF0 Rocker Switch Specifications:
- Contact Rating: 16A at 125VAC and 10A at 250VAC
- Mechanical Life Expectancy: 20,000 cycles
- Electrical Life Expectancy: 6,000 cycles
- Contact Resistance: 50 milliohms (initial)
- Insulation Resistance: 100 megaohms at 500V DC
- Dielectric Strength: 1,500V minimum for 1 minute
- Operating Temperature: 0°C to 65°C
- Features: SPST, SPOT, ON-OFF, neon or LED indicators, multiple configurations
- Physical Dimensions: Width 2.00 inches, Length 11.90 inches +0.1/-0.0
- Color Options: Black, White, Red, Yellow, Green
- Environmental Rating: Designed for industrial environments
Buy the Industrial Series Rocker Switch: RR3112D
Secure your industrial control needs by purchasing the RR3112D rocker switch online today. With a rated 16A at 125VAC, durable construction for 20,000 cycles, and optional neon or LED indicators, this switch ensures reliable operation and safety. Its versatile configurations support a range of applications, including lighting, audio/visual equipment, and machinery controls. Easy to install and operate, it combines durability, safety, and performance suitable for industrial, commercial, and technical markets. Enhance your system's reliability with this high-quality, visually appealing rocker switch available now online.
Buy RR3112D rocker switch now and experience unmatched reliability and performance in industrial controls and lighting applications.
