E-SWITCH RSC241D1B2R Industrial Control Switch
The RSC series switch offers high reliability and a variety of actuator options including illuminated, bi-color, and different terminal styles. Constructed with UL94 V-2 rated polyamide bodies and full polycarbonate lenses, these switches support a wide temperature range from -20°C to 125°C, with a lifespan of 10,000 cycles. Suitable for industrial control applications, the switches feature silver contacts, multiple ratings up to 6.3mm tab or large hole mounting, and robust electrical and insulation resistance. Versatile and durable, they are ideal for machinery, automation, and safety systems requiring precise switching.
E-SWITCH RSC241D1B2R Industrial Control Switch Specifications:
- Materials: Polyamide 6/6 UL94 V-2 body, full polycarbonate lens, silver contacts, silver-plated copper terminals
- Temperature Range: -20°C to 125°C, UL, cURus ratings supported
- Electrical Ratings: Up to 6.3A at 125V, 10A at 125V, 15A at 125V switch ratings
- Mechanical Life: 10,000 cycles, Contact Resistance: 20mΩ max at 1A 5VDC
- Insulation Resistance: 100MQ minimum at 500VDC, Dielectric Strength: 1000VAC for 1 minute
- Physical Dimensions: Various cutout sizes including 28.6x13.9mm, 27.2x12.1mm, with large and small hole options
- Actuator Types: Solder, flat, curved, with illumination and bi-color options, rated for various voltages and currents
- Mounting Options: Tab, On-On, Off-On, with optional illumination and custom markings
- Certifications: UL Listed, cULus, European standards
Buy the WAEK NM – Reliable Switches for Industrial Applications
Discover our durable industrial control switches designed with high-quality materials and versatile options for automation, machinery, and safety applications. Featuring multiple actuator types, ratings, and mounting styles, these switches ensure reliable performance even in demanding environments. Supported by UL and cURus certifications, they provide long-lasting operation with a lifespan of 10,000 cycles. Easy to install and customizable, our switches are your ideal solution for industrial automation, control panels, and safety systems. Purchase online today for fast delivery and excellent support.
Buy WAEK NM switches now and benefit from high current capacity, durable materials, and versatile mounting options for your industrial control needs.
Frequently Asked Questions
Where can I buy E-SWITCH RSC241D1B2R?
You can click on the BUY or RFQ button to purchase RSC241D1B2R from an authorized E-SWITCH distributor.
How do I troubleshoot issues or seek technical support for part RSC241D1B2R?
You can download the RSC241D1B2R datasheet or visit the E-SWITCH website for support.
Who is the manufacturer of RSC241D1B2R?
E-SWITCH
