E-SWITCH TL1275CA2WA500QPG Tactile Switch
The TL1275 series tactile switch features a reliable SPST contact arrangement with 500mm long wire leads and connectors, suitable for various industrial applications. It offers a contact rating of 50mA at 12VDC, with options for single-color and bi-color LEDs. The switch exhibits a contact resistance of 100mΩ initially, a dielectric strength of 250V RMS, and an operating temperature range of -25°C to 70°C. Its compact design supports a maximum panel thickness of 3.5mm, with a travel of 0.25mm and actuation force of 350gf, ensuring precise tactile response and durability over 100,000 cycles.
E-SWITCH TL1275CA2WA500QPG Tactile Switch Specifications:
- Contact Arrangement: SPST with 500mm long wire leads and connectors
- Contact Rating: 50mA @ 12VDC
- Contact Resistance: 100mΩ initial
- Insulation Resistance: 100 MΩ minimum
- Dielectric Strength: 250V RMS
- Electrical Life: 100,000 cycles
- Operating Temperature: -25°C to 70°C
- Storage Temperature: -25°C to 70°C
- Travel: 0.25mm ± 0.1mm
- Actuation Force: 350gf ± 100gf
- Panel Thickness: maximum 3.5mm
- Wire Gauge: 26 AWG AWM, 300V, 105°C
- Housing Material: Not specified
- LED Options: P-illuminated with colors including red, blue, green, white, yellow, red-green
- Connector: JSW A2541H-2P
- Terminals: JSW A2547T-GP
- Dimensions: Not specified, supports panel layout according to keyway alignment
Buy the Generic TL1275 – Reliable Tactile Switch for Industrial Applications
Purchase the TL1275 tactile switch online now to ensure reliable operation in your industrial, defense, or automation projects. Featuring a SPST contact with a 500mm long wire leads, this switch offers exceptional durability with a contact rating of 50mA at 12VDC and a lifespan of 100,000 cycles. Its compact design supports panel thicknesses up to 3.5mm and features LED illumination options for better visibility. Great for panel mount, detection, and navigation applications, order now to boost your project reliability and efficiency.
Order your generic TL1275 tactile switch today and enhance your control panels with dependable, long-lasting performance for industrial environments.
Frequently Asked Questions
Where can I buy E-SWITCH TL1275CA2WA500QPG?
You can click on the BUY or RFQ button to purchase TL1275CA2WA500QPG from an authorized E-SWITCH distributor.
How do I troubleshoot issues or seek technical support for part TL1275CA2WA500QPG?
You can download the TL1275CA2WA500QPG datasheet or visit the E-SWITCH website for support.
Who is the manufacturer of TL1275CA2WA500QPG?
E-SWITCH
