E-SWITCH TL6275BA2PQRG Toggle Switch
The TL6275 Series is a range of reliable toggle, pushbutton, rocker, rotary, slide, snap action, and keylock switches suitable for industrial applications, including anti-vandal and detector functionalities. Featuring SPST contact arrangement with a 50mA @ 12VDC rating, these switches offer a contact resistance of 100mΩ, dielectric strength of 250V RMS, and an electrical life of 100,000 cycles. Designed for operation within -25°C to 70°C, they support PCB mounting with through-hole pins, various illumination options, and water wash resistance for robust, versatile performance in demanding environments.
E-SWITCH TL6275BA2PQRG Toggle Switch Specifications:
- Contact Arrangement: SPST
- Contact Rating: 50mA @ 12VDC
- Contact Resistance: 100mΩ Initial
- Insulation Resistance: 100 MQ Min.
- Dielectric Strength: 250V RMS
- Electrical Life: 100,000 cycles
- Operating Temperature: -25°C to 70°C
- Storage Temperature: -25°C to 70°C
- Travel: 0.25mm
- Actuation Force: 350 gf
- Mounting: PCB through-hole pins
- Cap options: Transparent, Opaque, Translucent, High Square, Circle
- Illumination: LED compatible with various colors
- Water wash resistance: Capable to withstand water wash processes
- Dimensions: Actuator length approximately 7.20 mm for standard, various sizes for caps
- Material: Copper alloy contacts, plastic actuators
- Certifications: UL, RoHS compliant
Buy the Bey TL6275 – Reliable Toggle Switch for Industrial Applications
Discover the high-quality Bey Series TL6275 toggle switch, engineered for durability and water resistance, ideal for industrial control panels. With a robust SPST contact configuration rated at 50mA @ 12VDC, this switch can withstand 100,000 cycles of operation, ensuring long-term performance. Its PCB mounting design, various cap options including translucent and opaque, and LED illumination capability make it versatile for multiple applications. Easily order online to enhance your automation systems with trusted switch technology.
Order your Bey Series TL6275 toggle switch today and equip your projects with dependable, durable switches suited for demanding industrial environments.
Frequently Asked Questions
Where can I buy E-SWITCH TL6275BA2PQRG?
You can click on the BUY or RFQ button to purchase TL6275BA2PQRG from an authorized E-SWITCH distributor.
How do I troubleshoot issues or seek technical support for part TL6275BA2PQRG?
You can download the TL6275BA2PQRG datasheet or visit the E-SWITCH website for support.
Who is the manufacturer of TL6275BA2PQRG?
E-SWITCH
