E-SWITCH WB246D1929 Power Switch
The WB246D1929 is a robust double-pole double-throw power rocker switch designed for industrial use. It features a durable black polyamide 6/6 actuator and silver-plated brass terminals for reliable electrical connection. The switch’s body is made from polyamide 6/6 with internal protection rated at IP55, ensuring dust and water resistance. It operates between -20°C and 65°C and has a high insulation resistance of 500 megaohms. Suitable for controlling electric power in machinery and industrial environments, this switch provides excellent durability and safety.
E-SWITCH WB246D1929 Power Switch Specifications:
- Body Material: Polyamide 6/6
- Actuator Material: Polyamide 6/6
- Terminal Material: Silver Plated Brass
- Sealing: Ethylene Propylene Rubber Seal
- Ingress Protection: IP55
- Insulation Resistance: 500 Megaohms
- Dielectric Strength: 1,500 VAC for 1 Minute
- Temperature Range: -20°C to 65°C
- Rated Current: 20A at 125/250VAC
- Power Rating: 2.0 HP at 125/250VAC
- Contact Resistance: 50 mΩ Max
- Operating Temperature: Min -20°C, Max 65°C
Buy the Buy Industrial Power Switch Part Number WB246D1929 Online
Purchase the WB246D1929 power rocker switch online for industrial applications. It features IP55 water and dust protection, high insulation resistance, and a durable polyamide body. Suitable for machinery and control panels, this switch operates reliably in temperatures from -20°C to 65°C. Its silver-plated brass terminals ensure excellent electrical contact, making it ideal for demanding environments. Order now and ensure your equipment benefits from durable, safe, and industry-standard switching solutions with fast delivery and excellent support.
Get WB246D1929 power rocker switch today—engineered for industrial reliability and long-lasting performance.
Frequently Asked Questions
Where can I buy E-SWITCH WB246D1929?
You can click on the BUY or RFQ button to purchase WB246D1929 from an authorized E-SWITCH distributor.
How do I troubleshoot issues or seek technical support for part WB246D1929?
You can download the WB246D1929 datasheet or visit the E-SWITCH website for support.
Who is the manufacturer of WB246D1929?
E-SWITCH
