ebm-papst 3550 Multi-Conductor Cable
The Alpha Wire 3550 is a multi-conductor cable designed for a wide range of industrial applications. It consists of 10 parallel conductors, each insulated with PVC, providing excellent insulation and flexibility. The cable meets UL and military specifications, ensuring high performance and reliability. It is RoHS compliant, minimizing environmental impact, and REACH compliant, demonstrating commitment to chemical safety. This cable is ideal for applications requiring multiple conductors in a compact and durable design, such as control panels, instrumentation, and power distribution systems.
ebm-papst 3550 Multi-Conductor Cable Specifications:
- Component 1 Conductor: 26 (7/34) AWG TC
- Insulation Wall: 0.010" Nom. PVC
- Color Cond 1: BROWN
- Color Cond 2: RED
- Color Cond 3: ORANGE
- Color Cond 4: YELLOW
- Color Cond 5: GREEN
- Color Cond 6: BLUE
- Color Cond 7: VIOLET
- Color Cond 8: SLATE
- Color Cond 9: WHITE
- Color Cond 10: BLACK
- Cable Assembly: 10 Components assembled parallel
- Diameters In: 0.019 - 0.039
- Cable Dimensions: 0.039 +/- 0.002 x 0.390 +/- 0.020
- UL Style: AWM/STYLE 2713
- Voltage Rating: 80°C / 150 VRMS
- VW-1: Yes
- Military Spec: MIL-DTL-16878/1 (Type B)
- Military Voltage: 105°C / 600 VRMS
- Temperature Range: -55 to 105°C
- Bend Radius: 10X Cable Diameter
- Pull Tension: 21.8 Lbs, Maximum
- Voltage Rating (Electrical): 600 VRMS
- Capacitance: 28 pf/ft @1 kHz, Nominal Conductor to Conductor
- Inductance: 0.2 µH/ft, Nominal
- Conductor DCR: 41 Ω/1000ft @20°C, Nominal
- Packaging Length: 100 FT
- Packaging Dimensions: 11 x 0.5 x 3 inches
Buy the 3550 ebm-papst Multi-Conductor Cable | myMectronic
Purchase the Alpha Wire 3550 multi-conductor cable securely and efficiently to ensure your project's success.
