ebm-papst W1G250HH3752 Axial Fan
The W1G250-HH37-52 is an EC axial compact fan with sickled blades from the S series, designed for reliable airflow in industrial ventilation and cooling applications. It features a robust construction with a black-coated sheet steel fan body, die-cast aluminium blades, and a wall ring, ensuring durability. Operating efficiently at 24 VDC with a power input of 105 W and capable of speeds up to 2750 RPM, it supports a maximum back pressure of 140 Pa. Suitable for ambient temperatures from 25°C to 60°C, it offers IP 42 protection and easy control via 0-10 VDC or PWM signals, with features including soft start and reverse polarity protection.
ebm-papst W1G250HH3752 Axial Fan Specifications:
- Mass: 24 kg
- Size: 250 mm diameter
- Surface of rotor: Coated in black
- Material of blades: Die-cast aluminium
- Material of wall ring: Coated sheet steel
- Number of blades: 7
- Direction of air flow: Counter-clockwise, seen on rotor
- Type of protection: IP 42
- Insulation class: 3
- Max. permissible ambient motor temp.: +80°C
- Min. permissible ambient motor temp.: 40°C
- Mounting position: Any
- Operation mode: S1 (continuous operation)
- Motor bearing: Ball bearing
- Electrical Leads: Control input 0-10 VDC / PWM, tach output, reverse polarity and locked-rotor protection
- EC compliant: EN 61000-6-2, EN 55022 (Class B)
- Approval: UL, CSA, EAC, EN 60950-1
- Nominal voltage: 24 VDC
- Speed range: up to 2750 RPM
- Power input: 105 W
- Max back pressure: 140 Pa
- Ambient temperature range: -25°C to +60°C
Buy the Ebmpapst Series S Axial Fan: W1G250HH3752
Looking for a durable industrial axial fan? The Ebmpapst Series S compact axial fan W1G250HH3752 offers high efficiency, robust construction, and flexible control options. Ideal for cooling and ventilation, it features sickled blades, a black-coated steel housing, and die-cast aluminium blades for long-lasting performance. With a maximum speed of 2750 RPM, 105 W power, and IP 42 protection, this fan ensures reliable operation in ambient temperatures up to 60°C. Order online today for fast delivery and optimal airflow solutions.
Order your Ebmpapst Series S axial compact fan W1G250HH3752 today and give your industrial cooling or ventilation projects the dependable quality they deserve.
Frequently Asked Questions
Where can I buy ebm-papst W1G250HH3752?
You can click on the BUY or RFQ button to purchase W1G250HH3752 from an authorized ebm-papst distributor.
How do I troubleshoot issues or seek technical support for part W1G250HH3752?
You can download the W1G250HH3752 datasheet or visit the ebm-papst website for support.
Who is the manufacturer of W1G250HH3752?
ebm-papst
