EECO 4A210002G Miniature Timing Relay
The EECO 4A210002G is a miniature electropneumatic timing relay known for its high repeat accuracy and robust design. Its sealed timing head utilizes a circular-path dial head, replacing traditional needle valves for easy linear adjustment. The relay is suitable for applications requiring precise timing control in environments with high shock and vibration. It offers a wide range of timing adjustments and is available in various configurations for different operating voltages and mounting options.
EECO 4A210002G Miniature Timing Relay Specifications:
- High Repeat Accuracy: Over voltage and temperature extremes
- Hermetically Sealed: Designed for high shock and vibration applications
- Recycling: Instant recycling — easy linear adjustment
- Adjustment: Exclusive Dial Head adjustment — no needle valves
- Delay Ranges: Milliseconds to 3 minutes
- Contacts: DPDT contacts
- Sealed Timing Head: Circulates air under controlled pressure
- Switch Assembly: Snap-action switch assembly provides sustained contact pressure
- Solenoid Assembly: Precision-wound solenoid supplies motive force
- Reset Time: 2112 Series: 25 msec.
- Relay Release Time: 25 msec. (2112 Series)
- Relay Operate Time: 75 msec. (2122 Series)
- Operating Voltage: See table for details
- Dielectric: 1000V RMS @ 60Hz between non-connected terminals
- Contact Rating (DPDT Contacts): See table for details
- Ambient Temperature Range: -55°C to +85°C
- Weight: Maximum, any unit - 17 ozs.
- Mounting/Terminals: Chassis mounting tabs, octal plugs, solder hook terminals
Buy the 4A210002G EECO Miniature Timing Relay | myMectronic
Purchase the EECO 4A210002G Miniature Timing Relay securely and reliably online.
Buy Now
Frequently Asked Questions
Where can I buy EECO 4A210002G?
You can click on the BUY or RFQ button to purchase 4A210002G from an authorized EECO distributor.
How do I troubleshoot issues or seek technical support for part 4A210002G?
You can download the 4A210002G datasheet or visit the EECO website for support.
Who is the manufacturer of 4A210002G?
EECO
