Eaton - Cutler Hammer XTOM004AC1 Miniature Overload Relay
The XTOM004AC1 is an IEC power control miniature overload relay with a 45mm mini frame, 10A trip class, suitable for small motors up to 5 HP or 4 kW. It features phase failure sensitivity, manual/auto reset, auxiliary contacts, test button, and trip-free release. Compatible with XTMC and XTMF contactors, ideal for light-duty applications like hoisting, material handling, heating, lighting, and automation. Its compact design and reliable protection make it perfect for small electrical motors, providing efficient overload and phase loss detection within industrial automation systems.
Eaton - Cutler Hammer XTOM004AC1 Miniature Overload Relay Specifications:
- Standards: IEC/EN 60947, UL, CSA, VDE
- Trip Class: 10A
- Frame Size: 45mm
- Current Range: 0.1-10A
- Overload Protection Type: Bimetallic
- Suitable for Motors up to 5 HP or 4 kW
- Mounting: Direct to XTMC and XTMF contactors
- Features: Phase failure sensitivity, manual/auto reset, auxiliary contacts, test/off button, trip-free release
- Ambient Temperature (Open): 25/80°C, (Enclosed): 25/40°C
- Rated Operational Voltage: 690V AC
Buy the Buy Eaton IEC Power Control Part Number XTOM004AC1 Online
Order the Eaton XTOM004AC1 miniature overload relay online to ensure efficient motor protection up to 5 HP. This reliable relay features phase failure detection, manual and automatic reset options, auxiliary contacts, and a test button for easy maintenance. Its compact 45mm frame design allows straightforward mounting on XT contactors, ideal for automation, lighting, heating, and material handling applications. Enhance your motor control setup today with this durable, high-performance overload relay for small electrical motors.
Buy Eaton XTOM004AC1 now and experience unmatched reliability and performance for small motor overload protection in automation systems.
Frequently Asked Questions
Where can I buy Eaton - Cutler Hammer XTOM004AC1?
You can click on the BUY or RFQ button to purchase XTOM004AC1 from an authorized Eaton - Cutler Hammer distributor.
How do I troubleshoot issues or seek technical support for part XTOM004AC1?
You can download the XTOM004AC1 datasheet or visit the Eaton - Cutler Hammer website for support.
Who is the manufacturer of XTOM004AC1?
Eaton - Cutler Hammer
