Eaton Bussmann LP-CC-1/2 Datasheet & Stock

The LP-CC-1/2 is a 500mA Low-Peak™ ultimate protection Cass CC current-limiting Time-delay Fuse provides close sizing on small motor and relay circuits and maximum component short-circuit current rating protection. 200kA interrupting rating complies with NEC® Section 110.9 for today's large capacity systems. Fast short-circuit protection and dual-element, time-delay performance provide ultimate protection. Reduces existing fuse inventory by up to 33% when upgrading to low-peak fuses. Consistent 2:1 ampacity ratios for all Low-Peak fuses make selective coordination easy. Time-delay characteristic avoids unwanted fuse openings from surge currents while fast response speed under short-circuit conditions provides a high degree of current limitation. Current-limitation protects downstream components against damaging thermal and magnetic effects of short-circuit currents. A superior, all-purpose, space-saving branch circuit fuse meets most protection requirements up to 30A.




Very compact design with rejection tip

Superior protection for small horsepower motor circuits

Class CC rejection feature, with fuse block, prevents inserting lesser-rated supplementary fuses

200kA at VAC, 20kA at VDC Interrupting rating





Applications


Industrial
