Eaton Bussmann LPCC5 Low-Peak Fuse
The LP-CC-5 is a Low-Peak current-limiting fuse rated for 5A, designed for maximum protection in 600VAC and 300VDC systems. Featuring fast short-circuit response and dual-element, time-delay performance, it effectively prevents unwanted fuse openings during surges while providing reliable overcurrent protection. Its compact size and consistent 2:1 ampacity ratios facilitate easy upgrade and inventory reduction. Suitable for small motor circuits, it offers a 200kA AC RMS symmetrical and 20kA VDC interrupting rating, complying with NEC standards and ensuring space-efficient, superior short-circuit and overload protection for industrial and control systems.
Eaton Bussmann LPCC5 Low-Peak Fuse Specifications:
- Rated Current: 5 Amps
- Voltage Rating: 600Vac / 300Vdc
- Interrupting Rating: 200kA AC RMS, 20kA VDC
- Time-Delay: Dual-element, minimum 12 seconds
- Features: Current-limiting, space-saving, high capacity
- Standards: UL Listed, CSA Certified, NEC compliant
- Physical Size: Compact design, approximately 0.41 inches (10.3 mm) in diameter
- Suitable for small motor circuits and control applications
- Replaces larger fuse inventories and reduces costs
- Reinforced for surge and short-circuit protection
Buy the Eaton Series LP Low-Peak Fuse: LPCC5
Secure your electrical systems with the Eaton LPCC5 fused device, engineered for high-capacity, space-efficient, and reliable overload and short-circuit protection. Its dual-element, time-delay design ensures long-term safety and performance for motors and control circuits. Offering a 200kA interrupting rating and NEC compliance, this fuse reduces inventory costs and simplifies system upgrades. Compatible with various fuse blocks and holders, it guarantees easy installation and superior performance, making it an essential component for industrial automation, control panels, and motor protection applications.
Buy Eaton LPCC5 now and experience unmatched reliability and protection for your electrical systems.
Frequently Asked Questions
Where can I buy Eaton Bussmann LPCC5?
You can click on the BUY or RFQ button to purchase LPCC5 from an authorized Eaton Bussmann distributor.
How do I troubleshoot issues or seek technical support for part LPCC5?
You can download the LPCC5 datasheet or visit the Eaton Bussmann website for support.
Who is the manufacturer of LPCC5?
Eaton Bussmann
