Eaton Bussmann SC60 Size-Rejecting Fuse
This Class G size-rejecting fuse provides reliable overcurrent protection with both time-delay and fast-acting options, suitable for general-purpose electrical circuits up to 600V. Rated for 1/2 to 60 amps, it features a cylindrical package measuring approximately 10.30 mm in diameter and 57.15 mm in length, ensuring secure mounting. Compliant with UL, CSA, CE, and RoHS standards, it meets NEC and Canadian Electrical Code requirements. Ideal for protecting circuits in industrial, commercial, and residential environments, the fuse offers high interrupting ratings and is designed for cost-effective, reliable circuit overcurrent protection.
Eaton Bussmann SC60 Size-Rejecting Fuse Specifications:
- Voltage Rating: 600Vac, 170Vde (220A); 480Vac, 300Vdc (25-60A)
- Current Rating: 1/2-60A
- Interrupting Rating: 100kA Vac RMS Sym., 10kA Vde
- Dimensions: Diameter 10.30 mm, Length 57.15 mm
- Standards: UL Listed, CSA Certified, RoHS Compliant, CE Certified
- Type: Size-rejecting, time-delay and fast-acting
- Application: General-purpose, circuit protection
- Mounting: Suitable for fuse holders, cylindrical package
- Features: Meets NEC and CEC requirements, high interrupting capacity
Buy the Buy Bussmann Class G Size Rejection Fuse Part Number SC60 Online
Purchase the Bussmann Class G size-rejecting fuse online today to ensure reliable circuit protection, high interrupting capacity, and compliance with industry safety standards. This fuse is suitable for general-purpose applications in industrial, commercial, and residential environments, rated up to 600V and 60A. Its cylindrical package allows for secure installation, and it features advanced current limiting and overload delay characteristics. By buying online, you gain quick access to a proven solution for safeguarding electrical systems against overcurrent conditions, ensuring operational safety and efficiency.
Get Bussmann SC60 today—designed for high reliability, overcurrent protection in industrial and commercial circuits.
Frequently Asked Questions
Where can I buy Eaton Bussmann SC60?
You can click on the BUY or RFQ button to purchase SC60 from an authorized Eaton Bussmann distributor.
How do I troubleshoot issues or seek technical support for part SC60?
You can download the SC60 datasheet or visit the Eaton Bussmann website for support.
Who is the manufacturer of SC60?
Eaton Bussmann
