Eaton Bussmann SS5H1AAP Time-Delay Fuse
The SS-5H fuse is a 300V subminiature, radial leaded, time-delay fuse designed for primary and secondary circuit protection across various applications including power supplies, notebooks, appliances, lighting ballasts, and LED displays. It features a small rectangular-leaded design that saves board space, high breaking capacity, UL recognition, and compliance with IEC, VDE, TUV, and PSE standards. Halogen-free and lead-free, it offers reliable overcurrent protection and vibration resistance suitable for demanding environments.
Eaton Bussmann SS5H1AAP Time-Delay Fuse Specifications:
- Voltage Rating: 300V AC, 250V AC versions available
- Interrupting Rating: 100A at 300V AC
- Time delay: Yes (fast-acting)
- Construction: Radial leaded, small rectangular design
- Standards: UL Recognized, IEC80127-3, VDE, TUV, PSE compliant
- Materials: Flammability UL 94V0, halogen free, lead free, ROHS compliant
- Operating Temperature: -40°C to 125°C
- Soldering: Not recommended for reflow; manual soldering at 350°C for 4-5 sec
- Vibration Resistance: MIL-STD-202F, 10-55Hz
- Dimensions: Lead length approximately 4.3mm or 21mm depending on packaging
- Packaging: Ammo pack, polybag options, pitch 12.7mm
Buy the BUSSMANN SS-5H – Reliable Time-Delay Fuses for Industrial Applications
Secure your electrical systems with the BUSSMANN SS-5H fuse, a reliable 300V subminiature, radial leaded device ideal for power supplies, LED displays, and white goods. Its high breaking capacity and UL recognition ensure safety and durability across various industrial applications. Designed to meet international standards including IEC, VDE, TUV, and PSE, it provides excellent overcurrent protection with a compact design that saves valuable circuit board space. Easy to install, halogen free, and lead free, it guarantees optimal performance in demanding environments and vibrations.
Order your BUSSMANN Series SS-5H fuse today and ensure dependable overcurrent protection for your critical circuits and appliances.
