Eaton Bussmann SS5H5AAPH Time-Delay Fuse
The SS-5H series is a high-capacity, time-delay fuse designed for protection in various electronic devices. Featuring a radial leaded design, it withstands high vibration and operates safely up to 300V AC. Compliant with IEC 60127-3 standards, these fuses provide reliable overcurrent protection for power supplies, chargers, and electronic displays while offering UL, VDE, TUV, and other certifications. Halogen-free and RoHS compliant, they ensure safety, durability, and environmentally friendly operation, suitable for a wide range of electronic and electrical applications.
Eaton Bussmann SS5H5AAPH Time-Delay Fuse Specifications:
- Voltage Rating: 300Vac
- Interrupting Rating: 100A
- Rated Current: 1A to 6.3A
- Operating Temperature Range: -40°C to 85°C
- Storage Temperature: -10°C to 40°C
- Flammability: UL 94V-0
- Material: Halogen-free
- Solderability: EIA-186-9E Method 9
- Vibration Resistance: MIL-STD-202F, Method 201A
- Soldering Temperature: 260°C for 10 seconds
- Dimensions: Specific to model, approximately 15x21x2.75 mm
- Agency Approvals: cURus, VDE, TUV, CQC, PSE, KC-Mark
Buy the Buy Cooper Bussmann SS-5H Series Time Delay Fuse Part Number SS5H5AAPH Online
Secure your electronic protection needs with the Cooper Bussmann SS-5H series fuse. Offering high breaking capacity, reliable overload protection, and certified safety standards, these fuses are ideal for power supplies, chargers, and displays. Their radial leaded design reduces PCB space usage while ensuring durability through rigorous vibration and temperature resistance testing. Halogen-free and RoHS compliant, they provide eco-friendly operation for diverse industrial and consumer applications. Purchase online now for fast delivery and trusted quality assurance.
Get Cooper Bussmann SS-5H Series high-capacity time-delay fuse today—designed for reliable overcurrent protection in power supplies and electronic devices.
Frequently Asked Questions
Where can I buy Eaton Bussmann SS5H5AAPH?
You can click on the BUY or RFQ button to purchase SS5H5AAPH from an authorized Eaton Bussmann distributor.
How do I troubleshoot issues or seek technical support for part SS5H5AAPH?
You can download the SS5H5AAPH datasheet or visit the Eaton Bussmann website for support.
Who is the manufacturer of SS5H5AAPH?
Eaton Bussmann
