Eaton Bussmann TR1350HV1R High Voltage Fuse
The high voltage fast-acting brick fuse is designed for primary and secondary circuit protection in server, telecom, and power conversion systems. Featuring a ceramic tube with silver-plated caps, this fuse handles voltages up to 500 V, with current ratings ranging from 1A to 5A. It offers high interrupting ratings, fast response times, and is RoHS compliant. Suitable for applications like DC-DC converters, power factor correction, and capacitor output protection, ensuring reliable overcurrent protection with robust standards compliance and excellent thermal resistance.
Eaton Bussmann TR1350HV1R High Voltage Fuse Specifications:
- Voltage Rating: 500 V
- Current Ratings: 1A to 5A
- Interrupting Rating: 100A @ 500 Vde
- Response Time: Fast-acting, typically 1 second at rated current
- Construction: Ceramic tube with silver-plated caps
- Moisture Sensitivity Level: MSL 1
- Temperature Range: -40 °C to +125 °C
- Standards: RoHS compliant, cURus recognized
- Package: Surface mount, 11 x 5.0 x 5.0 mm, compatible with recommended pad layouts
- Environmental Resistance: Thermal shock MIL-STD-202, vibration MIL-STD-202G, resistance to solder heat MIL-STD-202G, solderability J-STD-002
Buy the Eaton Series 1145HV High Voltage Fast-Acting Fuse: TR1350HV1R
Purchase the Eaton TR1350HV1R high voltage fast-acting fuse online today and ensure reliable protection for your power systems. Designed for rapid response in critical circuits, this fuse offers high interrupting ratings up to 100A at 500V, with robust ceramic construction and RoHS compliance. Ideal for server, telecom, DC-DC converter, and capacitor protection applications, ensuring safety and durability. Order now to benefit from fast delivery, authentic Eaton quality, and expert support for your circuit protection needs.
Buy Eaton TR1350HV1R now and experience unmatched reliability and performance in high voltage circuit protection.
