Eaton Bussmann TR1350HV5R High Voltage Fast-Acting Fuse
The TR1350HV5R is an automotive high voltage fast-acting brick fuse designed for primary and secondary circuit protection in electric vehicle battery systems, power distribution units, and high-voltage DC-DC converters. This ceramic tube fuse features a 500 VDC voltage rating, silver-plated cap construction, and certified automotive grade qualification. Its compact 11x5.0x5.0 mm surface mount package ensures reliable performance under harsh conditions, including temperature cycling, humidity, vibration, and shock. It also offers excellent moisture resistance and mechanical durability suitable for demanding automotive and industrial applications.
Eaton Bussmann TR1350HV5R High Voltage Fast-Acting Fuse Specifications:
- Voltage Rating: 500 VDC
- Package Size: 11x5.0x5.0 mm surface mount
- Construction: Ceramic tube, silver-plated cap
- Temperature Range: -55°C to +125°C with derating
- Automotive Grade Certified
- Moisture Sensitivity Level: MSL 1
- Interrupting Ratings: 125% In for 120 sec, 200% In for 1 sec, 1000% In maximum for short duration
- Operating Temperature: -55°C to +125°C
- Vibration: MIL-STD-202 method 204
- Mechanical Shock: MIL-STD-202 method 213
- Humidity Bias: MIL-STD-202 method 103
- Solderability: J-STD-002, steam aging and immersion
- Board Flex: AEC-0200-005, 2 mm minimum flex
Buy the Eaton Series 1145HVA Automotive High Voltage Fuse: TR1350HV5R
Purchase the Eaton TR1350HV5R high voltage fuse online for reliable circuit protection in electric vehicles, power supplies, and industrial systems. This ceramic tube fuse rated at 500 VDC features a compact 11x5.0x5.0 mm surface mount design, ensuring easy installation and robust performance even under harsh conditions. Certified as automotive grade, it withstands temperature cycling, vibration, humidity, and shock to provide safe and effective protection for critical electrical circuits. Order now to enjoy fast shipping and OEM-quality reliability for your high voltage applications.
Get Eaton TR1350HV5R today—built for high voltage protection and long-lasting durability in automotive and industrial applications.
Frequently Asked Questions
Where can I buy Eaton Bussmann TR1350HV5R?
You can click on the BUY or RFQ button to purchase TR1350HV5R from an authorized Eaton Bussmann distributor.
How do I troubleshoot issues or seek technical support for part TR1350HV5R?
You can download the TR1350HV5R datasheet or visit the Eaton Bussmann website for support.
Who is the manufacturer of TR1350HV5R?
Eaton Bussmann
