Eaton Electronics PSG480B24RM Power Backup Buffer Module
The buffer module for the PSG power supply unit provides reliable backup during brief power outages, extending operation time by operating in parallel. It features an input voltage range of 228-288 V DC and supplies a nominal output of 24 V DC at 20 A, with adjustable voltage settings between 22-28 V DC. The module supports backup durations from 250 ms up to over 5 seconds depending on load, with quick charging within 30 seconds and a robust aluminum housing. Ideal for industrial automation requiring dependable power backup solutions.
Eaton Electronics PSG480B24RM Power Backup Buffer Module Specifications:
- Input voltage range: 228-288 V DC
- Rated output voltage: Typically 24 V DC
- Output current: Max. 20 A
- Backup time: >250 ms at 20 A load, >5 seconds at 1 A load
- Setting range for output voltage: 22-28 V DC
- Charging mode current: <0.6 A
- Discharging mode max current: 20 A
- Maximum input signal voltage: 35 V, 10 mA
- Housing material: Aluminum
- Dimensions: Height 121 mm, width 70 mm, depth 120.1 mm
- Efficiency: Low ripple (<200 mVpp at 20 MHz)
- MTBF: >800,000 hours
- Protections: Overvoltage, short-circuit, parallel connection capable
Buy the Eaton Series Buffer Module: Power Backup Buffer Module PSG480B24RM
Secure your industrial automation system with the Eaton PSG480B24RM buffer module. It offers quick charging, reliable backup of up to 5 seconds at 20 A, and can be connected in parallel for extended operation. Its adjustable output voltage range of 22 to 28 V ensures flexibility across various setups. Designed with quality aluminum housing, it withstands harsh environments while providing stable power during outages, preventing operational interruptions and safeguarding your critical equipment.
Buy Eaton PSG480B24RM buffer module now and experience unmatched reliability and performance for industrial power backup applications.
