EDAC 307012524201 Card Edge Connector
This is a card edge connector with a contact spacing of 0.156 inches (3.96 mm) and a total of 12 contacts. It features PCB tails measuring 0.023 x 0.013 inches (0.58 x 0.33 mm) with a tail length of 0.213 inches (5.41 mm). The connector does not include mounting lugs, making it suitable for applications requiring direct connection to a PCB without additional mounting hardware. It supports various mounting options, including mounting holes and floating eyelets, and is RoHS compliant and UL certified for reliable performance in electronic assemblies.
EDAC 307012524201 Card Edge Connector Specifications:
- Contact Spacing: 0.156 inches (3.96 mm)
- Total Number of Contacts: 12
- PCB Tails: 0.023 x 0.013 inches (0.58 x 0.33 mm)
- Tail Length: 0.213 inches (5.41 mm)
- Insulator Material: UL 94V-0 Thermoplastic Polyester
- Maximum Operating Temperature: -40°C to +105°C
- Contact Material: Copper Alloy
- Contact Plating: Gold on mating area, Tin on tails, Nickel underplating
- Current Rating: 5 amps
- Contact Resistance: 10 milliohms maximum
- Dielectric Withstanding Voltage: 1800 V AC rms between contacts
- Insulation Resistance: 5000 megaohms minimum
- Mounting Options: No mounting lugs, mounting holes, floating eyelets, threaded inserts
- Certifications: RoHS Compliant, UL Certified
Buy the EDAC Series 307 Series Card Edge Connector: 307012524201
Purchase the EDAC card edge connector online today and enhance your electronic projects with a high-quality, versatile connection solution. Designed for durability and precision, this connector supports various mounting options to suit your application needs. With a contact spacing of 0.156 inches and a total of 12 contacts, it ensures excellent electrical performance. Its RoHS compliance and UL certification guarantee safety and environmental standards. Order now for fast delivery and seamless integration into your manufacturing process.
Buy EDAC 307012524201 now and experience reliable connection quality for your electronic assemblies with versatile mounting options and high durability.
