EDAC 570290761 Wire to Wire Connector
The EDAC 572 series connector is a robust solution for wire-to-wire and wire-to-board applications. Designed with a 5.8mm pitch, it offers a secure and reliable connection while maintaining a compact form factor. The connector's fully waterproof design, featuring a double latch solution and IP67 certification, makes it ideal for harsh environments. It's available in various configurations, including different numbers of positions and wire sizes, and offers internal polarization to prevent mismating. The pre-assembled housing seals simplify installation and ensure a watertight seal.
EDAC 570290761 Wire to Wire Connector Specifications:
- Pitch: 5.8mm
- Rated Current: 10A max
- Waterproof: Fully Waterproof with Double Latch Solution
- Positions Available: 1, 2, or 3
- Crimp Solution: True Crimp and Poke Solution
- Polarization: Internal Polarization to Prevent Mismating
- Wire Sizes: Wide range of wire sizes available
- Waterproof Grade: IP67 Certified
- PCB Thickness: 1.6mm
- Withstanding Voltage: 1700V AC(rms)
- Contact Resistance: 10 mΩ max
- Insulation Resistance: 1000 MΩ
- Temperature Range: -40°C to +105°C
- Rated Voltage: 300V
- AWG Range: 20-16, 22-20
- Insulation Diameter Max: 3.1mm, 2.7mm
- Housing Material: PBT with Glass, UL 94V-0
- Contact Material: PBT, UL 94V-0
- Contact Plating: Tin Plating
- Wire Seal Material: Silicone Rubber
- Contact Availability: Crimp Contacts are also available in strips of 40pcs.
- Ordering Guide: NO. OF CONTACTS: 001 - 1 CONTACT, 002 - 2 CONTACTS, 003 - 3 CONTACTS; CONTACT CODE: 000 - NO CONTACTS, 420 - BOARD MOUNT CONTACTS; STYLE: 101 - WHITE MALE HOUSING, 301 - BLUE MALE HOUSING, 100 - WHITE MALE HOUSING FOR CRIMP CONTACTS, 300 - BLUE MALE HOUSING FOR CRIMP CONTACTS, 200 - WHITE FEMALE HOUSING FOR CRIMP CONTACTS, 400 - BLUE FEMALE HOUSING FOR CRIMP CONTACTS
