EXTECH PRC15 Process Calibrator
The Extech PRC15 is a compact, versatile calibration device designed for process control and instrumentation calibration. It features a 0 to 24 mA current source with adjustable range from -25% to 125%, and a 0 to 20V DC calibration source. The device includes five programmable calibration presets, a large backlit LCD for clear readings, and standard banana jack I/O ports. Powered by a large battery bank with an external adapter, it provides extended operation for testing transmitters, transducers, indicators, and sensors in laboratory or field environments, ensuring precise calibration and troubleshooting of process devices.
EXTECH PRC15 Process Calibrator Specifications:
- Range: Source 0 to 24mA with load up to 1000 ohms (-25% to 125%), 0 to 20V (PRC15 only)
- Measure: 0 to 50mA current signal (-25% to 230%), 0 to 19.99V (PRC15 only)
- Power/Measure: Provides 24V DC power for loops and measures current (PRC10 only)
- Input/Output Ranges: 0 to 19.99mA (0.01mA resolution), 0 to 24.0mA (0.1mA resolution), 0 to 1999mV (tmV resolution), 0 to 20.00V (10mV resolution)
- Accuracy: 0.01% + 1 digit
- Dimensions: 6.3 x 3.2 x 1.7 inches (159 x 80 x 44mm)
- Weight: 8.202 ounces (232g), excluding batteries
- Power: 100V-240V AC adapter and six AA batteries included
- Features: Large backlit LCD, five calibration presets, standard banana jack ports, external power option, robust housing
Buy the Extech Series PRC15 Current & Voltage Calibrator: PRC15
Get the Extech PRC15 process calibrator online today and enjoy precise current and voltage calibration for transmitters, sensors, and control devices. Its programmable presets, large backlit LCD, and extended battery life make it perfect for field and laboratory use. Whether calibrating process transmitters, transducers, or indicators, this compact device ensures accurate diagnostics and troubleshooting, minimizing downtime. Purchase now to enhance your calibration accuracy and operational efficiency with reliable, easy-to-use instrumentation designed for professional use.
Buy Extech PRC15 now and experience unmatched reliability and performance with its versatile calibration features ideal for process testing and maintenance.
Frequently Asked Questions
Where can I buy EXTECH PRC15?
You can click on the BUY or RFQ button to purchase PRC15 from an authorized EXTECH distributor.
How do I troubleshoot issues or seek technical support for part PRC15?
You can download the PRC15 datasheet or visit the EXTECH website for support.
Who is the manufacturer of PRC15?
EXTECH
