EXTECH PRC20 Thermocouple Calibrator
The Extech PRC20 is a portable thermocouple calibrator that sources and measures eight thermocouple types, including J, K, T, E, C, R, S, and N. It features a large backlit LCD display, multiple user calibration presets, high accuracy calibration functions, and simulates precise thermocouple outputs for calibration of thermometers, transmitters, controllers, and recorders. The device displays measurements in millivolts or temperature based on thermocouple tables, has a mini thermocouple input, a large battery bank for extended use, and an external power adapter for continuous operation. Its compact, durable design suits lab, field calibration, engineering research, HVAC, and temperature troubleshooting applications, ensuring reliable, precise readings and calibration verification.
EXTECH PRC20 Thermocouple Calibrator Specifications:
- Range: Type J -58 to 1832°F (50 to 100°C), Type K -58 to 2498°F (50 to 1370°C), Type T -184 to 752°F (120 to 400°C), Type E -58 to 1382°F (50 to 750°C), Type C 32 to 3182°F (to 1750°C), Type R/S 32 to 3182°F (to 1750°C), Type N -58 to 2372°F (50 to 1300°C)
- Basic Accuracy: 0.05% reading
- Resolution: 0.1°C up to 999.9 or 1°C over 999.9 for J, K, T, E; 1°C for R, N; 0.5°C for C, S
- Input Impedance: 10 MΩ
- Sampling Rate: 4 times per second
- Display: Large backlit LCD with thermocouple type indication
- Meter Dimensions: 6.3 x 3.2 x 1.7 inches (159 x 80 x 44 mm)
- Weight: Approximately 8 oz (225 g), excluding batteries
- Power Options: 100V-240V AC adaptor, 6 x 1.5V AA batteries included
- Calibration: Adjustable presets, external calibration cable included
- Compatibility: Mini thermocouple input for type J, K, T, E, C, R, S, N
- Additional Features: Cold junction compensation, simulated thermocouple output for calibration, durable housing suitable for field and lab use
Buy the Buy Extech PRC20 Thermocouple Calibrator Part Number PRC20 Online
Purchase the Extech PRC20 thermocouple calibrator online today for precise, reliable temperature calibration across various thermocouple types. Its high accuracy, large backlit LCD, multiple calibration presets, and portable design make it ideal for lab, field, HVAC, and industrial applications. With features like cold junction compensation, simulated outputs, and external power options, the PRC20 ensures excellent performance and durability. Simplify your calibration processes and achieve consistent, precise temperature measurements by ordering this essential calibration device online now.
Get Extech PRC20 thermocouple calibrator today—compact, high-accuracy device perfect for lab and field calibration tasks.
Frequently Asked Questions
Where can I buy EXTECH PRC20?
You can click on the BUY or RFQ button to purchase PRC20 from an authorized EXTECH distributor.
How do I troubleshoot issues or seek technical support for part PRC20?
You can download the PRC20 datasheet or visit the EXTECH website for support.
Who is the manufacturer of PRC20?
EXTECH
