FINDER 223400244720 Power Contactor
This power contactor features a coil voltage of 24 VAC or VDC, with a contact configuration of three normally open (3PST-NO) and one normally closed (SPST-NC). It supports a current rating of 25 amps, supports DIN rail mounting, and provides reliable switching performance for control applications. Equipped with reinforced insulation, mechanical and LED indicators, and silent AC/DC coils with varistor protection, it is suitable for resistive, inductive, and motor loads, ensuring efficient operation in industrial automation systems.
FINDER 223400244720 Power Contactor Specifications:
- Rated current: 25 A
- Contact configuration: 3 NO + 1 NC
- Rated voltage: 250/440 VAC
- Rated load: 6250 VA AC1 / AC7a
- Coil voltage: 24 VAC or VDC
- Coil consumption: 2/22 VA/W
- Mechanical life: 2-10^8 cycles
- Electrical life at rated load: 30-10^4 cycles
- Operate/release time: 30/20 ms
- Insulation between coil and contacts: 6 kV
- Operating temperature: -20°C to +50°C
- Protection category: 1P20
- Suitable for resistive, inductive, motor, and lamp loads
- Supports DIN rail mounting (35 mm)
- Contact gap: 3 mm for NO contacts, >1.5 mm for NC contacts
- Fast transient immunity: EN 61000-4-4 level 4
- Rated impulse voltage: 6 kV between coil and contact set
Buy the Finder Series 22 Power Contactor: 223400244720
Buy your Finder Series 22 Power Contactor with 25 A switching capacity and 24 VAC/VDC coil online today. Designed for DIN rail mounting, it offers robust insulation, LED indicators, silent operation, and versatile load handling. Its reinforced insulation and quick-assembly auxiliary modules make installation and maintenance simple. Perfect for industrial automation, motor control, and resistive or inductive loads, this contactor guarantees durable, efficient performance in demanding electrical environments. Secure yours now for reliable project execution.
Order your Finder Series 22 power contactor 223400244720 today and ensure reliable control with efficient switching and safety features.
