FINDER 348170129024 Solid State Relay
This solid state relay is designed for control with a 12 VDC input voltage. It supports a load current of up to 2 amps and is suitable for loads operating at 24 VDC. The relay features a single normally open (NO) output configuration and is mounted on a printed circuit board (PCB). It provides silent, high-speed switching with long electrical life, insulation between input and output of 2,500 V, and is suitable for various automation and control applications requiring reliable switching of DC loads. Its compact design allows for easy integration into electronic systems and control panels.
FINDER 348170129024 Solid State Relay Specifications:
- Input Voltage: 12 VDC
- Rated Load Current: 2 A
- Load Voltage: 24 VDC
- Output circuit: 1 NO (SPST-NO)
- Insulation between input and output: 2,500 V
- Maximum continuous load: 2 A
- Control current: 7 mA
- Dielectric strength: 2,500 V
- Operating temperature range: -20°C to +70°C
- Environmental protection: IP20
- Connector type: PCB mount
- Power loss in relay: 0.4 W
- Dimensions: Compact PCB footprint
- Approval: Suitable for industrial automation use
Buy the Innovative Series Solid State Relay: 348170129024
Order the Solid State Relay with part number 348170129024 online today and enhance your automation setup. This relay offers reliable, silent high-speed switching of DC loads up to 2 amps at 24 VDC. Its compact, PCB-mounted design makes it easy to integrate into control panels and electronic systems. With insulation of 2,500 V and a long electrical lifespan, it is ideal for industrial automation, home automation, and control applications. Protect your equipment with a dependable switching solution. Buy online now for quick delivery and seamless integration.
Get Innovate Series Solid State Relay 348170129024 today—built for precision and long-lasting durability in electronic control systems.
