FINDER 465290120040 Industrial Power Relay
High-reliability industrial power relay designed for socket mount or direct connection via Faston connectors. Features AC and DC coils, lockable test button, mechanical and LED indicators, and cadmium-free contacts. Suitable for control panels, automation systems, and industrial equipment with isolation of 6 KV, enhanced EMC suppression modules, and options for various mounting adaptors. Compatible with terminal sockets, PCB mounts, and rail adapters, ensuring flexible installation and high operational durability in demanding environments.
FINDER 465290120040 Industrial Power Relay Specifications:
- Contact Configuration: 2.CO (DPDT), 1.CO (SPDT)
- Rated Current: 8/16A, Max Peak Current: 15/25A
- Switching Voltage (VAC): 250/440
- Rated Load (VAC): 2000 - 4000 VA
- AC1 Load (VA): 2000 - 4000
- Mechanical Life: 10^10 cycles
- Electrical Life at Rated Load: 100,000 cycles
- Insulation Voltage: 6 KV (8mm), 6 KV (Reinforced)
- Dielectric Strength: 1000 VAC between open contacts, 4000 VAC coil to contact
- Ambient Temperature Range: -40°C to +70°C
- Coil Voltage: 12V, 24V, 48V, 110V, 125V, 230V, 240V AC/DC
- Resistance: 80Ω (24V DC), 264Ω (48V DC), 253Ω (230V AC)
- Operating Range: 0.8...1.1 Un
- Dropout Voltage: 0.2 Un (AC/DC), Holding Voltage: 0.8 Un
- Vibration Resistance: 20 g, Shock Resistance: 20 g
- Protection Category: IP20
- Approvals: CE, UL (see technical datasheet)
Buy the Finder 465290120040 – Reliable Industrial Power Relay for Industrial Applications
Order the Finder industrial power relay 465290120040 online today. Designed for robust industrial control with AC/DC coils, lockable test button, LED indicators, and cadmium-free contacts. Perfect for automation, control panels, and manufacturing processes, offering high isolation of 6 KV, EMC suppression modules, and flexible mounting options including sockets, PCB mounts, and rail adaptors. Ensure long-lasting performance with this reliable relay tailored for tough industrial applications. Shop now to improve your system’s reliability and efficiency.
Get Finder 465290120040 today—built for precision, durability, and versatile control in demanding industrial environments.
Frequently Asked Questions
Where can I buy FINDER 465290120040?
You can click on the BUY or RFQ button to purchase 465290120040 from an authorized FINDER distributor.
How do I troubleshoot issues or seek technical support for part 465290120040?
You can download the 465290120040 datasheet or visit the FINDER website for support.
Who is the manufacturer of 465290120040?
FINDER
